R.6.28
SEL-421 Relay Reference Manual Date Code 20111215
DNP3 Communications
Application Example
Settings
Figure 6.2 shows how to enter the new map into the relay. Use the SET D
command and enter N at the prompts shown in Figure 6.2 to allow changes to
the existing maps. Press <Enter> at the line prompt to advance to the next
map. For example, press <Enter> at line 10 of the Binary Input Map to
advance to the Binary Output Map.
=>>SET D <Enter>
DNP
DNP Reference Map Selection
Reference Map Selection (B,E) MAPSEL := B ? <Enter>
DNP Object Default Map Enables
Use default DNP map for Binary Inputs (Y/N) DNPBID := Y ?N <Enter>
Use default DNP map for Binary Outputs (Y/N) DNPBOD := Y ?N <Enter>
Use default DNP map for Counters (Y/N) DNPCOD := Y ? <Enter>
Use default DNP map for Analog Inputs (Y/N) DNPAID := Y ?N <Enter>
Use default DNP map for Analog Outputs (Y/N) DNPAOD := Y ? <Enter>
Binary Input Map
(Index Number)
? 7 <Enter>
2:
? 6 <Enter>
3:
? 1024 <Enter>
4:
? 1025 <Enter>
5:
? 1026 <Enter>
6:
? 1027 <Enter>
7:
? 479 <Enter>
8:
(Continued on next page)
? 478 <Enter>
LICFM
a
,
LICFA
b
30 4, 5 5, 6 IC magnitude and
angle
VA F M
c
,
VA FA
b
30 36, 37 7, 8 VAY magnitude and
angle
VBFM
c
,
VBFA
b
30 38, 39 9, 10 VBY magnitude and
angle
VCFM
c
,
VCFA
b
30 40, 41 11, 12 VCY magnitude and
angle
3P_f
d
30 87 13 Three-phase real
power in MW
3Q_f
d
30 91 14 Three-phase reactive
power in MVAR
DC1
e
30 100 15 DC1 voltage
multiplied by 100
ACTGRP 40 0 0 Active settings group
a
Assume the largest expected current is 2000 A, scale the analog value by a factor of 10 to
provide a resolution of 0.1 A and a maximum current of 3276.7 A. Report change events on a
change of 5 A.
b
Angles are scaled to 1/100 of a degree. Report change events on a change of 2 degrees.
c
For a nominal voltage of 230 kV, scale the analog value by a factor of 100 to provide a
resolution of 10 V and a maximum value of 327.67 kV. Report 1 kV for change event reporting.
d
For a maximum load of 800 MW (or 800 mVar), scale the power by a factor of 40 to provide a
resolution of 0.025 MW, and a maximum value of 819.175 MW. Report 1 MW for change event
reporting.
e
VDC1 is scaled by a factor of 1/100 of a volt. Report change events on a change of 2 V.
Table 6.17 DNP3 Application Example Data Map (Sheet 2 of 2)
Name Object
Default Map
Index
Custom
Map Index
Description
