Operation - Work application
6 - 56
830 / 07.2012
Original operating instructions
Extend single outrigger
(optional)
1 Apply the parking and service brakes.
2 Start the engine in accordance with Section 4.10.4.
3 Release the safety lever (see Section 6.3.2).
4 Lock the floating axle with the switch on the front right of the
control panel (the lamp in the switch does not light up).
5 Push the lever for actuating all supports (1) forward until the
outriggers are extended completely. Then pull the lever back
until the wheels are in contact with the ground.
1 Apply the parking and service brakes.
2 Start the engine in accordance with Section 4.10.4.
3 Release the safety lever (see Section 6.3.2).
4 Lock the floating axle with the switch on the front right of the
control panel (the lamp in the switch does not light up).
5 On uneven ground, make sure to level the machine by using
the individual outrigger feet.
– Press the switch (14) (and hold pressed) and
simultaneously press the lever (1) forwards.
Release the switch (2).
– Press the switch (15) (and hold pressed) and
simultaneously press the lever (1) forwards.
Release the switch (3).
– Press the switch (16) (and hold pressed) and
simultaneously press the lever (1) forwards.
Release the switch (5).
– Press the switch (17) (and hold pressed) and
simultaneously press the lever (1) forwards.
Release the switch (4).
