Technical data
12.2 Technical data, Power Modules
Inverter with CU230P-2 Control Units
Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
379
Table 12- 3 PM230, IP20, Frame Sizes A, 3 AC 380 V … 480 V
Order No. - without filter
Order No. - with filter
6SL3210…
6SL3210…
…1NE17-7UL0
…1NE17-7AL0
LO power
LO input current
LO output current
3 kW
8.0 A
7.7 A
HO power
HO input current
HO output current
2.2 kW
6.1 A
5.9 A
Fuse according to IEC
Fuse according to UL
3NE1 813-0
AJT10 / 3NE1 813-0
Power loss
0.11 kW
Required cooling air flow
4.5 l/s
Cross section of line and motor cables 1.5 … 2.5 mm
2
16 … 14 AWG
Tightening torque for line and motor cables
0.5 Nm / 4 lbf in
Weight, unfiltered
Weight, filtered
1.4 kg
1.6 kg
Table 12- 4 PM230, PT, Frame Sizes A, 3 AC 380 V … 480 V
Order No. - without filter
Order No. - with filter
6SL3211…
6SL3211…
…1NE17-7UL0
…1NE17-7AL0
LO power
LO input current
LO output current
3 kW
8.0 A
7.7 A
HO power
HO input current
HO output current
2.2 kW
6.1 A
5.9 A
Fuse according to IEC
Fuse according to UL
3NE1 813-0
AJT10 / 3NE1 813-0
Power loss
0.11 kW
Required cooling air flow
4.5 l/s
Cross section of line and motor cables 1.5 … 2.5 mm
2
16 … 14 AWG
Tightening torque for line and motor cables
0.5 Nm / 4 lbf in
Weight, unfiltered
Weight, filtered
1.7 kg
1.9 kg
