Operation 4
Traction
Roadways
Dimensions of roadways and aisle widths
The following dimensions and aisle width
requirements apply under the specified
conditions to ensure safe manoeuvring. In
each case, a check must be performed to
determine whether a larger aisle width is
necessary, e.g. in the case of deviating load
dimensions, attachments, lift masts and tow
couplings.
Within the EU, "Council Dir
ective 89/654/EEC
concerning the minimum saf
ety and health
requirements for the workp
lace" must be
observed. The respective
national guidelines
apply for areas outside th
eEU.
The required aisle widths depend on the
dimensions of the load.
Required aisle widths wi
th pallet
Aisle width [mm]
Model
Type
With pallet
1000x1200
crosswise
With pallet
800x1200
lengthwise
RX20-14C 6219 3186 3311
RX20-16C 6220 3186 3311
RX20-16 6221 3269 3394
RX20-16L 6222 3377 3502
RX20-18 6223 3269 3394
RX20-18L 6224 3377 3502
RX20-20L 6225 3390 3516
RX20-16P 6226 3362 3487
RX20-16PL 6227 3470 3595
RX20-18P 6228 3362 3487
RX20-18PL 6229 3470 3595
RX20-20P 6230 3375 3501
RX20-20PL 6231 3483 3609
Thetruckmayonlybeusedondrivewaysthat
do not have curves that are too tight, have
gradients that are too steep, and entrances
that are not too narrow or low.
563
68011531 EN - 06/2019 - 02 135
