Nameplate
The truck can be identified from the informa-
tion on the nameplate.
1Type
2 Producti
on number
3 Year of manufacture
4 Tare weight in kilograms
5 Maximum
permitted battery weight in
kilogr
ams (only for electric trucks)
6 Minimum permitted battery weight in
kilograms (only for electric trucks)
7 Ballast weight in kilograms (only for
electric trucks)
8Datama
trix code
9 For more detailed information, refer
to the technical data in the operating
instructions
10 CE labelling
11 Nominal
drive power in kilowatts
12 Battery voltage V
13 Rated capacity in kilograms
