Operation 4
Handling loads
Settingdownaload
DANGER
Risk of accident due to changed moment of tilt!
The load centre of gravity and the moment of tilt
move due to tilting the lift mast forwards with a
raised load or due to the load slipping. The truck
may tip forwards.
– Only tilt the lift mast forwards with a raised lifting
accessory when it is directly above the stack.
– When the lift mast is tilted forwards, take parti-
cular care to ensure that the truck does not tip
forwards and that the load does not slip.
WARNING
Risk of accident f
rom falling load!
If the fork or the
load remains suspended during
lowering, the lo
ad may fall.
– When removing f
rom stock, move the truck far
enough back so t
hat the load and the fork can be
lowered freel
y.
– Drive up to the stack with the load lowered
in accordance with regulations.
– Set the lift mast to vertical.
– Lift the loa
d to the stacking height.
– Drive the truck towards the rack carefully.
563
68011531 EN - 06/2019 - 02 203
