Still RX20-20L - RX20-20 Swing Axle VDI Datasheet

6 Technical data
RX20-20 swing axle VDI datasheet
RX20-20 swing axle VDI
datasheet
NOTE
This VDI datasheet specifies only the technical
values for trucks with standard equipment.
Different tyres, lift masts, additional units etc.
can produce different values.
Key data
Model
RX20-20P RX20-20PL
Type number
6230 6231
Manufacturer STILL GmbH STILL GmbH
Drive Electric Electric
Operation
Seat Seat
Rated capacity/load Q (kg)
2000 2000
Load centre of gravity distance c (mm)
500 500
Load distance
x(mm)
388 388
Wheelbase
y(mm)
1429 1537
.
Weights
Model
RX20-20P RX20-20PL
Type number
6230 6231
Net weight kg
3474 3449
Front axle load, laden
kg
4858 4851
Rear axle load, laden
kg
616 598
Front axle load, unladen
kg
1616 1696
Rear axle load, unladen
kg
1858 1754
.
Wheels, chassis frame
Model RX20-20P RX20-20PL
Type number
6230 6231
Tyres
Superelastic Superelastic
Tyre size, front
200/50-10 200/50-10
422
