Operation 4
Transporting the truck
CAUTION
Abrasive lashing straps/tension belts can rub
against the surface of the truck and cause damage.
– Position slip-resistant pads (e.g. rubber mats or
foam) underneath the lifting points.
– Hook the lashing straps/
tension belts onto
both sides of the curves i
n the mudguard
and lash the truck toward
s the rear.
– Position the lashing straps/tension belts for
the coupling pin around the coupling pin
as shown and lash the truck at an angle
towards the front.
Crane loading
Crane loading is only intended for transporting
the complete truck, including the lift mast,
for its initial commissioning. This may be
performed only by the authorised service
centre with the harnesses expressly provided
and approved for this purpose.
563
68011531 EN - 06/2019 - 02 349
