Technical data 6
VDI datasheet: RX20-18 and RX20-20
with steering turntable
VDI datasheet: RX20-18
and RX20-20 with steering
turntable
NOTE
This VDI datasheet specifies only the technical
values for trucks with standard equipment.
Different tyres, lift masts, additional units etc.
can produce different values.
Key data
Model
RX20-18 RX20-18L RX20-20L
Type number
6223 6224 6225
Manufacturer STILL GmbH STILL GmbH STILL GmbH
Drive Electric Electric Electric
Operation
Seat Seat Seat
Rated capacity/load Q (kg)
1800 1800 2000
Load centre of gravity distance c (mm)
500 500 500
Load distance
x (mm)
374 374 388
Wheelbase
y (mm)
1409 1517 1517
.
Weights
Model
RX20-18 RX20-18L RX20-20L
Type number
6223 6224 6225
Net weight kg
3231 3419 3486
Front axle load, laden
kg
4440 4450 4860
Rear axle load, laden
kg
590 769 623
Front axle load, unladen
kg
1524 1612 1689
Rear axle load, unladen
kg
1707 1806 1794
.
563
68011531 EN - 06/2019 - 02 409
