6 Technical data
VDI datasheet: RX20-16 with swing a
xle
VDI datasheet: RX20-16 with
swing axle
NOTE
This VDI datasheet specifies only the technical
values for trucks with standard equipment.
Different tyres, lift masts, additional units etc.
can produce different values.
Key data
Model
RX20-16P RX20-16PL
Type number
6226 6227
Manufacturer STILL GmbH STILL GmbH
Drive Electric Electric
Operation
Seat Seat
Rated capacity/load Q (kg)
1600 1600
Load centre of gravity distance c (mm)
500 500
Load distance
x(mm)
374 374
Wheelbase
y(mm)
1429 1537
.
Weights
Model
RX20-16P RX20-16PL
Type number
6226 6227
Net weight kg
3018 3178
Front axle load, laden
kg
4098 4121
Rear axle load, laden
kg
520 657
Front axle load, unladen
kg
1520 1612
Rear axle load, unladen
kg
1498 1567
.
Wheels, chassis frame
Model RX20-16P RX20-16PL
Type number
6226 6227
Tyres
Superelastic Superelastic
Tyre size, front
180/70-8 180/70-8
414
