Still RX20-20L - Quadruple Mini-Lever

3 Overviews
Operating devices and display elem
ents
Quadruple mini-lever
1Drive
direction switch
2 "Tilt"
operating lever
3"Aux
iliary hydraulics 1" operating lever
4"
Auxiliary hydraulics 2" operating lever
5 Function key for the "5th function"
6 Signal h
orn button
7"F1"fu
nction key
8"Lif
t/lower" operating lever
9D
isplay field for the hydraulic functions
NOTE
The authorised service centre can assign
different functions to the "F1" function key.
