Technical data 6
RX20-20 swing axle VDI datasheet
Model RX20-20P RX20-20PL
Type number
6230 6231
Tyre size, rear
150/75-8 150/75-8
Number of front wheels
(x = driven)
2x 2x
Number of rear wheels
(x = driven)
22
Track width, front
b
10
(mm)
942 942
Track width, rear
b
11
(mm)
807 807
.
Basic dimensions
Model RX20-20P RX20-20PL
Type number
6230 6231
Forward tilt of lift mast/fork carriage α (degrees)
55
Backwards tilt of lift mast/fork
carriage
β (degrees)
66
Height with li
ft mast retracted
h
1
(mm)
2160 2160
Free lift
h
2
(mm)
150 150
Lift
h
3
(mm)
3180 3180
Height with lift mast extended h
4
(mm)
3742 3742
Height above overhead guard (cab) h
6
(mm) 2035 (1949) 2035 (1949)
Seat height/standing height h
7
(mm)
965 965
Coupling height h
10
(mm)
537 537
Overall length l
1
(mm)
2851 2959
Length including fork back l
2
(mm)
2051 2159
Overall width
b
1
(mm)
1149 1149
Fork arm thickness
s (mm)
40 40
Fork arm width
e (mm)
80 80
Fork arm length l (mm)
800 800
Fork carriage
Standard;
class; form
ISO
2328 II A
ISO
2328 II A
Fork carriage width
b
3
(mm)
980 980
Ground clearance with load below
lift mast
m
1
(mm)
≥90 ≥90
Ground clearance at the middle of
the wheelbase
m
2
(mm)
114 114
