4 Operation
Attachments
Picto-
gram
Attachment function
Close clamps
Rotate to the left
Rotate to the right
Tip shovel over
Tip shovel back
NOTE
The pictograms are affixed according to
the attachment fitted at the factory. If an
attachment with different functions is fitted,
the authorised service centre must check that
the pictograms bear the correct representation
and must change them if necessary.
– For actuation of the clamp locking mecha-
nism, see the section entitled "Clamp lock-
ing mechanism (variant)".
250
56368011531 EN - 06/2019 - 02
