Operation 4
Replacing and transporting the bat
tery
– Adjust the stop (1) so that the battery will
later be centred on the change frame.
NOTE
To pick up batteries with large trays, fasten the
side stop in the outer bores, e.g. tray 366.
Thebatterymustlieagainstthesidestop(1)
and against the stops (3).
– Re-tighten the screw joint (2).
– Position the change frame properly on the
lift truck until the fork arm tips are touching
the feet (9).
When the change frame is on the lift truck, the
feet (5, 9) must be positioned close to the fork
arms on both sides.
NOTE
When using narrow pallet trucks with a di-
stance of 400 mm between the outer edges of
the fork arms, the stop (8) must be removed.
When using pallet trucks with a distance of
≥ 525 mm between the outer edges of the fork
arms, the stop must be installed. The stop (8)
is connected to the battery change frame via
the screw joint (7).
563
68011531 EN - 06/2019 - 02 335
