Technical data 6
VDI datasheet: RX20-18 and RX20-20
with steering turntable
Model RX20-18 RX20-18L RX20-20L
Type number
6223 6224 6225
Fork carriage width b
3
(mm)
980 980 980
Ground clearance with load below
lift mast
m
1
(mm)
≥90 ≥90 ≥90
Ground clearance at the middle of
the wheelbase
m
2
(mm)
114 114 114
Aisle width for pallet
1000 x 1200 crosswise
A
st
(mm)
3269 3377 3390
Aisle width for pallet
800 x 1200 longitudinal
A
st
(mm)
3269 3377 3390
Turning radius
W
a
(mm)
1570 1678 1678
Smallest pivot point distance b
13
(mm)
———
.
Performance data
Model
RX20-18 RX20-18L RX20-20L
Type number
6223 6224 6225
Driving speed with load (Blue-
Q/STILL Classic/sprint mode)
km/h 16/16/20 16/16/20 16/16/20
Driving speed without load (Blue-
Q/STILL Classic/sprint mode)
km/h 16/16/20 16/16/20 16/16/20
Lifting speed with load (Blue-
Q/STILL Classic/sprint mode)
m/s 0.52 0.52 0.45
Lifting speed without load (Blue-
Q/STILL Classic/sprint mode)
m/s
0.75 0.75 0.63
Lower
ing speed with load
m/s
0.52 0.52 0.48
Lowe
ring speed without load
m/s
0.5 0.5 0.41
Pulling force with load
N 4900 4800 4800
Pulling force without load
N 5100 5100 5000
Max. pulling force with load
N 12000 12000 11900
Max. pulling force without load
N 7900 8500 8700
Climbing capability with load
%
18.6 18.6 15
Climbing capability without load
% 24 24 18.1
Max. climbing capability with load
% 25.1 25.3 23
Max. climbing capability without
load
% 26 28.3 27
Acceleration time with load (Blue-
Q/STILL Classic/sprint mode)
s
5.8/5.5/5.2 5.8/5.5/5.2 5.8/5.5/5.3
