6 Technical data
VDI datasheet: RX20-18 with swing a
xle
Model RX20-18P RX20-18PL
Type number
6228 6229
Aisle width for pallet
1000 x 1200 crosswise
A
st
(mm)
3362 3470
Aisle width for pallet
800 x 1200 longitudinal
A
st
(mm)
3487 3595
Turning radius
W
a
(mm)
1663 1771
Smallest pivot point distance b
13
(mm)
——
.
Performance data
Model
RX20-18P RX20-18PL
Type number
6228 6229
Driving speed with load (Blue-
Q/STILL Classic/sprint mode)
km/h 16/16/20 16/16/20
Driving speed without load (Blue-
Q/STILL Classic/sprint mode)
km/h 16/16/20 16/16/20
Lifting speed with load (Blue-
Q/STILL Classic/sprint mode)
m/s 0.52 0.52
Lifting speed without load (Blue-
Q/STILL Classic/sprint mode)
m/s
0.75 0.75
Lowering
speed with load
m/s
0.52 0.52
Lowerin
g speed without load
m/s
0.5 0.5
Pulling force with load
N 4800 4800
Pulling force without load
N 5000 5100
Max. pulling force with load
N 11900 12000
Max. pulling force without load
N 8000 8500
Climbing capability with load
%
18.6 18.6
Climbing capability without load
%2424
Ma
x. Climbing capability with load
% 24.8 25.4
Max. climbing capability without
load
%2628.6
Acceleration time with load (Blue-
Q/STILL Classic/sprint mode)
s
5.8/5.5/5.2 5.8/5.5/5.2
Acceleration time without load
(Blue-Q/STILL Classic/sprint mode)
s
5.4/5.1/4.8 5.4/5.1/4.8
Service brake
Electr. /
mech.
Electr. /
mech.
.
420
