Overviews 3
Driver's compartment
1 Handle
2 Parking brake lever
3 Steering wheel
4 Emergency off switch
5 Key switch or pushbutton
6 Compartment
7
Explosion-protection warning lights
8 Display-operating unit "STILL Easy Control"
9 Operating devices for hydraulic and driving
functions
10 Compartment for storing the operating
instructions and the hexagon socket wrench
for emergency lowering
11
Battery isolating switch
12
Driver's seat
13 Accelerator pedal
14 Brake pedal
15
Bottom plate
16
Pneumatic signal horn
17 Steering column adjustment lever
18
Reset button
On category 2 explosion-protected trucks,
the plastic parts are coated with a special
antistatic paint that prevents the build-up of
an electrostatic charge. The coated areas
are identified with the decal information
"ELECTRICALLY CONDUCTIVE".
NOTE
The truck equipment may differ from the
equipment shown.
563
68011531 EN - 06/2019 - 02 73
