Stober PK - Page 265

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PHQ831K (n
1N
= 3000 rpm, M
2acc,max
= 2800 Nm)
43 480 519 15 2.9 PHQ831_0055K402_0125 MB23 EZ502U 2010 2010 4084 69.62 1462/21 8.0 8.0 3400 3000 4000 14 400 83
43 480 519 15 2.9 PHQ831_0055K402_0125 MB23 EZ502U 2010 2010 4084 69.62 1462/21 12 8.0 3400 3000 4000 14 400 83
43 480 519 15 2.9 PHQ831_0055K402_0125 MB23 EZ502U 2010 2010 4084 69.62 1462/21 16 8.0 3400 3000 4000 14 400 83
43 480 538 15 2.9 PHQ831_0055K402_0125 MB33 EZ701U 1297 1300 5087 69.62 1462/21 16 15 3400 3000 4000 39 400 93
43 480 538 15 2.9 PHQ831_0055K402_0125 MB33 EZ701U 1297 1300 5087 69.62 1462/21 24 15 3400 3000 4000 39 400 93
43 629 720 20 2.2 PHQ831_0055K402_0125 MB23 EZ503U 2431 2430 4084 69.62 1462/21 8.0 15 3400 3000 4000 18 400 85
43 629 720 20 2.2 PHQ831_0055K402_0125 MB23 EZ503U 2431 2430 4084 69.62 1462/21 12 15 3400 3000 4000 18 400 85
43 778 934 25 1.8 PHQ831_0055K402_0125 MB33 EZ702U 2658 2660 5087 69.62 1462/21 16 15 3400 3000 4000 44 400 95
43 778 934 25 1.8 PHQ831_0055K402_0125 MB33 EZ702U 2658 2660 5087 69.62 1462/21 24 15 3400 3000 4000 44 400 95
43 875 1037 28 1.6 PHQ831_0055K402_0125 MB23 EZ505U 2431 2430 4084 69.62 1462/21 8.0 15 3400 3000 4000 22 400 88
43 875 1037 28 1.6 PHQ831_0055K402_0125 MB23 EZ505U 2431 2430 4084 69.62 1462/21 12 15 3400 3000 4000 22 400 88
47 407 507 14 3.4 PHQ831_0055K402_0115 MB23 EZ404U 1711 1710 3716 63.35 7095/112 8.0 8.0 3000 2600 4000 13 400 84
47 407 507 14 3.4 PHQ831_0055K402_0115 MB23 EZ404U 1711 1710 3716 63.35 7095/112 12 8.0 3000 2600 4000 13 400 84
47 407 507 14 3.4 PHQ831_0055K402_0115 MB23 EZ404U 1711 1710 3716 63.35 7095/112 16 8.0 3000 2600 4000 13 400 84
47 437 472 15 3.2 PHQ831_0055K402_0115 MB23 EZ502U 1829 1830 3716 63.35 7095/112 8.0 8.0 3000 2600 4000 15 400 83
47 437 472 15 3.2 PHQ831_0055K402_0115 MB23 EZ502U 1829 1830 3716 63.35 7095/112 12 8.0 3000 2600 4000 15 400 83
47 437 472 15 3.2 PHQ831_0055K402_0115 MB23 EZ502U 1829 1830 3716 63.35 7095/112 16 8.0 3000 2600 4000 15 400 83
47 437 490 15 3.2 PHQ831_0055K402_0115 MB33 EZ701U 1180 1180 5087 63.35 7095/112 16 15 3000 2600 4000 40 400 93
47 437 490 15 3.2 PHQ831_0055K402_0115 MB33 EZ701U 1180 1180 5087 63.35 7095/112 24 15 3000 2600 4000 40 400 93
47 572 655 20 2.4 PHQ831_0055K402_0115 MB23 EZ503U 2212 2210 3716 63.35 7095/112 8.0 15 3000 2600 4000 19 400 85
47 572 655 20 2.4 PHQ831_0055K402_0115 MB23 EZ503U 2212 2210 3716 63.35 7095/112 12 15 3000 2600 4000 19 400 85
47 708 849 24 2.0 PHQ831_0055K402_0115 MB33 EZ702U 2419 2420 5087 63.35 7095/112 16 15 3000 2600 4000 45 400 95
47 708 849 24 2.0 PHQ831_0055K402_0115 MB33 EZ702U 2419 2420 5087 63.35 7095/112 24 15 3000 2600 4000 45 400 95
47 796 944 27 1.8 PHQ831_0055K402_0115 MB23 EZ505U 2212 2210 3716 63.35 7095/112 8.0 15 3000 2600 4000 23 400 88
47 796 944 27 1.8 PHQ831_0055K402_0115 MB23 EZ505U 2212 2210 3716 63.35 7095/112 12 15 3000 2600 4000 23 400 88
54 357 445 14 3.9 PHQ831_0055K402_0100 MB23 EZ404U 1500 1500 3258 55.54 1333/24 8.0 8.0 3400 3000 4000 13 400 84
54 357 445 14 3.9 PHQ831_0055K402_0100 MB23 EZ404U 1500 1500 3258 55.54 1333/24 12 8.0 3400 3000 4000 13 400 84
54 357 445 14 3.9 PHQ831_0055K402_0100 MB23 EZ404U 1500 1500 3258 55.54 1333/24 16 8.0 3400 3000 4000 13 400 84
54 383 414 14 3.7 PHQ831_0055K402_0100 MB23 EZ502U 1603 1600 3258 55.54 1333/24 8.0 8.0 3400 3000 4000 15 400 83
54 383 414 14 3.7 PHQ831_0055K402_0100 MB23 EZ502U 1603 1600 3258 55.54 1333/24 12 8.0 3400 3000 4000 15 400 83
54 383 414 14 3.7 PHQ831_0055K402_0100 MB23 EZ502U 1603 1600 3258 55.54 1333/24 16 8.0 3400 3000 4000 15 400 83
54 383 429 14 3.7 PHQ831_0055K402_0100 MB33 EZ701U 1034 1030 5087 55.54 1333/24 16 15 3400 3000 4000 40 400 93
54 383 429 14 3.7 PHQ831_0055K402_0100 MB33 EZ701U 1034 1030 5087 55.54 1333/24 24 15 3400 3000 4000 40 400 93
54 383 429 14 3.7 PHQ831_0055K402_0100 MB33 EZ701U 1034 1030 5087 55.54 1333/24 32 15 3400 3000 4000 40 400 93
54 502 574 19 2.8 PHQ831_0055K402_0100 MB23 EZ503U 1939 1940 3258 55.54 1333/24 8.0 15 3400 3000 4000 18 400 85
54 502 574 19 2.8 PHQ831_0055K402_0100 MB23 EZ503U 1939 1940 3258 55.54 1333/24 12 15 3400 3000 4000 18 400 85
54 621 745 23 2.3 PHQ831_0055K402_0100 MB33 EZ702U 2120 2120 5087 55.54 1333/24 16 15 3400 3000 4000 45 400 95
54 621 745 23 2.3 PHQ831_0055K402_0100 MB33 EZ702U 2120 2120 5087 55.54 1333/24 24 15 3400 3000 4000 45 400 95
54 621 745 23 2.3 PHQ831_0055K402_0100 MB33 EZ702U 2120 2120 5087 55.54 1333/24 32 15 3400 3000 4000 45 400 95
54 698 827 26 2.0 PHQ831_0055K402_0100 MB23 EZ505U 1939 1940 3258 55.54 1333/24 8.0 15 3400 3000 4000 23 400 88
54 698 827 26 2.0 PHQ831_0055K402_0100 MB23 EZ505U 1939 1940 3258 55.54 1333/24 12 15 3400 3000 4000 23 400 88
59 326 407 13 4.3 PHQ831_0055K402_0092 MB23 EZ404U 1372 1370 2981 50.81 26015/512 8.0 8.0 3000 2600 4000 14 400 84
59 326 407 13 4.3 PHQ831_0055K402_0092 MB23 EZ404U 1372 1370 2981 50.81 26015/512 12 8.0 3000 2600 4000 14 400 84
59 326 407 13 4.3 PHQ831_0055K402_0092 MB23 EZ404U 1372 1370 2981 50.81 26015/512 16 8.0 3000 2600 4000 14 400 84
59 350 379 14 4.0 PHQ831_0055K402_0092 MB23 EZ502U 1467 1470 2981 50.81 26015/512 8.0 8.0 3000 2600 4000 16 400 83
59 350 379 14 4.0 PHQ831_0055K402_0092 MB23 EZ502U 1467 1470 2981 50.81 26015/512 12 8.0 3000 2600 4000 16 400 83
59 350 379 14 4.0 PHQ831_0055K402_0092 MB23 EZ502U 1467 1470 2981 50.81 26015/512 16 8.0 3000 2600 4000 16 400 83
59 350 393 14 4.0 PHQ831_0055K402_0092 MB33 EZ701U 946 950 5087 50.81 26015/512 16 15 3000 2600 4000 41 400 93
59 350 393 14 4.0 PHQ831_0055K402_0092 MB33 EZ701U 946 950 5087 50.81 26015/512 24 15 3000 2600 4000 41 400 93
59 350 393 14 4.0 PHQ831_0055K402_0092 MB33 EZ701U 946 950 5087 50.81 26015/512 32 15 3000 2600 4000 41 400 93
59 459 525 19 3.1 PHQ831_0055K402_0092 MB23 EZ503U 1774 1770 2981 50.81 26015/512 8.0 15 3000 2600 4000 20 400 85
59 459 525 19 3.1 PHQ831_0055K402_0092 MB23 EZ503U 1774 1770 2981 50.81 26015/512 12 15 3000 2600 4000 20 400 85
59 568 681 23 2.5 PHQ831_0055K402_0092 MB33 EZ702U 1940 1940 5087 50.81 26015/512 16 15 3000 2600 4000 46 400 95
59 568 681 23 2.5 PHQ831_0055K402_0092 MB33 EZ702U 1940 1940 5087 50.81 26015/512 24 15 3000 2600 4000 46 400 95
59 568 681 23 2.5 PHQ831_0055K402_0092 MB33 EZ702U 1940 1940 5087 50.81 26015/512 32 15 3000 2600 4000 46 400 95
59 639 757 26 2.2 PHQ831_0055K402_0092 MB23 EZ505U 1774 1770 2981 50.81 26015/512 8.0 15 3000 2600 4000 24 400 88
59 639 757 26 2.2 PHQ831_0055K402_0092 MB23 EZ505U 1774 1770 2981 50.81 26015/512 12 15 3000 2600 4000 24 400 88
59 781 984 32 1.8 PHQ831_0055K402_0092 MB33 EZ703U 2800 3080 5087 50.81 26015/512 16 32 3000 2600 4000 58 400 98
59 1008 1429 41 1.4 PHQ831_0055K402_0092 MB33 EZ705U 2800 3170 5087 50.81 26015/512 16 32 3000 2600 4000 71 400 103
65 296 369 13 4.7 PHQ831_0055K402_0084 MB23 EZ404U 1244 1240 2703 46.07 645/14 8.0 8.0 3000 2600 4000 14 400 84
65 296 369 13 4.7 PHQ831_0055K402_0084 MB23 EZ404U 1244 1240 2703 46.07 645/14 12 8.0 3000 2600 4000 14 400 84
65 296 369 13 4.7 PHQ831_0055K402_0084 MB23 EZ404U 1244 1240 2703 46.07 645/14 16 8.0 3000 2600 4000 14 400 84
65 317 343 14 4.4 PHQ831_0055K402_0084 MB23 EZ502U 1330 1330 2703 46.07 645/14 8.0 8.0 3000 2600 4000 16 400 83
65 317 343 14 4.4 PHQ831_0055K402_0084 MB23 EZ502U 1330 1330 2703 46.07 645/14 12 8.0 3000 2600 4000 16 400 83
9 PHQKright-angle planetary geared motors 9.2 Selection tables
265
