Stober PK - Page 266

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PHQ831K (n
1N
= 3000 rpm, M
2acc,max
= 2800 Nm)
65 317 343 14 4.4 PHQ831_0055K402_0084 MB23 EZ502U 1330 1330 2703 46.07 645/14 16 8.0 3000 2600 4000 16 400 83
65 317 356 14 4.4 PHQ831_0055K402_0084 MB33 EZ701U 858 860 5087 46.07 645/14 16 15 3000 2600 4000 41 400 93
65 317 356 14 4.4 PHQ831_0055K402_0084 MB33 EZ701U 858 860 5087 46.07 645/14 24 15 3000 2600 4000 41 400 93
65 317 356 14 4.4 PHQ831_0055K402_0084 MB33 EZ701U 858 860 5087 46.07 645/14 32 15 3000 2600 4000 41 400 93
65 317 356 14 4.4 PHQ831_0055K402_0084 MB33 EZ701U 858 860 5087 46.07 645/14 45 15 3000 2600 4000 41 400 93
65 416 476 18 3.4 PHQ831_0055K402_0084 MB23 EZ503U 1609 1610 2703 46.07 645/14 8.0 15 3000 2600 4000 19 400 85
65 416 476 18 3.4 PHQ831_0055K402_0084 MB23 EZ503U 1609 1610 2703 46.07 645/14 12 15 3000 2600 4000 19 400 85
65 515 618 22 2.7 PHQ831_0055K402_0084 MB33 EZ702U 1759 1760 5087 46.07 645/14 16 15 3000 2600 4000 46 400 95
65 515 618 22 2.7 PHQ831_0055K402_0084 MB33 EZ702U 1759 1760 5087 46.07 645/14 24 15 3000 2600 4000 46 400 95
65 515 618 22 2.7 PHQ831_0055K402_0084 MB33 EZ702U 1759 1760 5087 46.07 645/14 32 15 3000 2600 4000 46 400 95
65 515 618 22 2.7 PHQ831_0055K402_0084 MB33 EZ702U 1759 1760 5087 46.07 645/14 45 15 3000 2600 4000 46 400 95
65 579 686 25 2.4 PHQ831_0055K402_0084 MB23 EZ505U 1609 1610 2703 46.07 645/14 8.0 15 3000 2600 4000 24 400 88
65 579 686 25 2.4 PHQ831_0055K402_0084 MB23 EZ505U 1609 1610 2703 46.07 645/14 12 15 3000 2600 4000 24 400 88
65 708 892 31 2.0 PHQ831_0055K402_0084 MB33 EZ703U 2789 2790 5087 46.07 645/14 16 32 3000 2600 4000 58 400 98
65 708 892 31 2.0 PHQ831_0055K402_0084 MB33 EZ703U 2789 2790 5087 46.07 645/14 24 32 3000 2600 4000 58 400 98
65 914 1296 40 1.5 PHQ831_0055K402_0084 MB33 EZ705U 2800 3100 5087 46.07 645/14 16 32 3000 2600 4000 70 400 103
65 914 1296 40 1.5 PHQ831_0055K402_0084 MB33 EZ705U 2800 3100 5087 46.07 645/14 24 32 3000 2600 4000 70 400 103
73 283 317 13 5.0 PHQ831_0055K402_0075 MB33 EZ701U 764 760 5087 41.01 20339/496 16 15 2600 2200 3800 43 400 93
73 283 317 13 5.0 PHQ831_0055K402_0075 MB33 EZ701U 764 760 5087 41.01 20339/496 24 15 2600 2200 3800 43 400 93
73 283 317 13 5.0 PHQ831_0055K402_0075 MB33 EZ701U 764 760 5087 41.01 20339/496 32 15 2600 2200 3800 43 400 93
73 283 317 13 5.0 PHQ831_0055K402_0075 MB33 EZ701U 764 760 5087 41.01 20339/496 45 15 2600 2200 3800 43 400 93
73 458 550 22 3.1 PHQ831_0055K402_0075 MB33 EZ702U 1566 1570 5087 41.01 20339/496 16 15 2600 2200 3800 48 400 95
73 458 550 22 3.1 PHQ831_0055K402_0075 MB33 EZ702U 1566 1570 5087 41.01 20339/496 24 15 2600 2200 3800 48 400 95
73 458 550 22 3.1 PHQ831_0055K402_0075 MB33 EZ702U 1566 1570 5087 41.01 20339/496 32 15 2600 2200 3800 48 400 95
73 458 550 22 3.1 PHQ831_0055K402_0075 MB33 EZ702U 1566 1570 5087 41.01 20339/496 45 15 2600 2200 3800 48 400 95
73 630 794 30 2.2 PHQ831_0055K402_0075 MB33 EZ703U 2482 2480 5087 41.01 20339/496 16 32 2600 2200 3800 60 400 98
73 630 794 30 2.2 PHQ831_0055K402_0075 MB33 EZ703U 2482 2480 5087 41.01 20339/496 24 32 2600 2200 3800 60 400 98
73 630 794 30 2.2 PHQ831_0055K402_0075 MB33 EZ703U 2482 2480 5087 41.01 20339/496 32 32 2600 2200 3800 60 400 98
73 813 1153 39 1.7 PHQ831_0055K402_0075 MB33 EZ705U 2800 2980 5087 41.01 20339/496 16 32 2600 2200 3800 72 400 103
73 813 1153 39 1.7 PHQ831_0055K402_0075 MB33 EZ705U 2800 2980 5087 41.01 20339/496 24 32 2600 2200 3800 72 400 103
73 813 1153 39 1.7 PHQ831_0055K402_0075 MB33 EZ705U 2800 2980 5087 41.01 20339/496 32 32 2600 2200 3800 72 400 103
81 334 382 19 3.9 PHQ831_0055K402_0067 MB23 EZ503U 1290 1290 2168 36.95 2365/64 8.0 15 3000 2600 4000 21 400 85
81 334 382 19 3.9 PHQ831_0055K402_0067 MB23 EZ503U 1290 1290 2168 36.95 2365/64 12 15 3000 2600 4000 21 400 85
81 413 496 21 3.4 PHQ831_0055K402_0067 MB33 EZ702U 1411 1410 5087 36.95 2365/64 16 15 3000 2600 4000 47 400 95
81 413 496 21 3.4 PHQ831_0055K402_0067 MB33 EZ702U 1411 1410 5087 36.95 2365/64 24 15 3000 2600 4000 47 400 95
81 413 496 21 3.4 PHQ831_0055K402_0067 MB33 EZ702U 1411 1410 5087 36.95 2365/64 32 15 3000 2600 4000 47 400 95
81 413 496 21 3.4 PHQ831_0055K402_0067 MB33 EZ702U 1411 1410 5087 36.95 2365/64 45 15 3000 2600 4000 47 400 95
81 465 551 26 2.8 PHQ831_0055K402_0067 MB23 EZ505U 1290 1290 2168 36.95 2365/64 8.0 15 3000 2600 4000 25 400 88
81 465 551 26 2.8 PHQ831_0055K402_0067 MB23 EZ505U 1290 1290 2168 36.95 2365/64 12 15 3000 2600 4000 25 400 88
81 568 716 29 2.5 PHQ831_0055K402_0067 MB33 EZ703U 2237 2240 5087 36.95 2365/64 16 32 3000 2600 4000 59 400 98
81 568 716 29 2.5 PHQ831_0055K402_0067 MB33 EZ703U 2237 2240 5087 36.95 2365/64 24 32 3000 2600 4000 59 400 98
81 568 716 29 2.5 PHQ831_0055K402_0067 MB33 EZ703U 2237 2240 5087 36.95 2365/64 32 32 3000 2600 4000 59 400 98
81 733 1039 38 1.9 PHQ831_0055K402_0067 MB33 EZ705U 2800 2880 5087 36.95 2365/64 16 32 3000 2600 4000 71 400 103
81 733 1039 38 1.9 PHQ831_0055K402_0067 MB33 EZ705U 2800 2880 5087 36.95 2365/64 24 32 3000 2600 4000 71 400 103
81 733 1039 38 1.9 PHQ831_0055K402_0067 MB33 EZ705U 2800 2880 5087 36.95 2365/64 32 32 3000 2600 4000 71 400 103
91 369 443 21 3.8 PHQ831_0055K402_0060 MB33 EZ702U 1260 1260 5087 33.00 33/1 16 15 2600 2200 3800 50 400 95
91 369 443 21 3.8 PHQ831_0055K402_0060 MB33 EZ702U 1260 1260 5087 33.00 33/1 24 15 2600 2200 3800 50 400 95
91 369 443 21 3.8 PHQ831_0055K402_0060 MB33 EZ702U 1260 1260 5087 33.00 33/1 32 15 2600 2200 3800 50 400 95
91 369 443 21 3.8 PHQ831_0055K402_0060 MB33 EZ702U 1260 1260 5087 33.00 33/1 45 15 2600 2200 3800 50 400 95
91 507 639 28 2.8 PHQ831_0055K402_0060 MB33 EZ703U 1997 2000 5087 33.00 33/1 16 32 2600 2200 3800 62 400 98
91 507 639 28 2.8 PHQ831_0055K402_0060 MB33 EZ703U 1997 2000 5087 33.00 33/1 24 32 2600 2200 3800 62 400 98
91 507 639 28 2.8 PHQ831_0055K402_0060 MB33 EZ703U 1997 2000 5087 33.00 33/1 32 32 2600 2200 3800 62 400 98
91 507 639 28 2.8 PHQ831_0055K402_0060 MB33 EZ703U 1997 2000 5087 33.00 33/1 45 32 2600 2200 3800 62 400 98
91 655 928 37 2.1 PHQ831_0055K402_0060 MB33 EZ705U 2772 2770 5087 33.00 33/1 16 32 2600 2200 3800 74 400 103
91 655 928 37 2.1 PHQ831_0055K402_0060 MB33 EZ705U 2772 2770 5087 33.00 33/1 24 32 2600 2200 3800 74 400 103
91 655 928 37 2.1 PHQ831_0055K402_0060 MB33 EZ705U 2772 2770 5087 33.00 33/1 32 32 2600 2200 3800 74 400 103
91 655 928 37 2.1 PHQ831_0055K402_0060 MB33 EZ705U 2772 2770 5087 33.00 33/1 45 32 2600 2200 3800 74 400 103
101 333 400 20 4.2 PHQ831_0055K402_0054 MB33 EZ702U 1139 1140 5087 29.82 1849/62 16 15 2600 2200 3800 49 400 95
101 333 400 20 4.2 PHQ831_0055K402_0054 MB33 EZ702U 1139 1140 5087 29.82 1849/62 24 15 2600 2200 3800 49 400 95
101 333 400 20 4.2 PHQ831_0055K402_0054 MB33 EZ702U 1139 1140 5087 29.82 1849/62 32 15 2600 2200 3800 49 400 95
101 333 400 20 4.2 PHQ831_0055K402_0054 MB33 EZ702U 1139 1140 5087 29.82 1849/62 45 15 2600 2200 3800 49 400 95
101 458 578 28 3.1 PHQ831_0055K402_0054 MB33 EZ703U 1805 1810 5087 29.82 1849/62 16 32 2600 2200 3800 61 400 98
101 458 578 28 3.1 PHQ831_0055K402_0054 MB33 EZ703U 1805 1810 5087 29.82 1849/62 24 32 2600 2200 3800 61 400 98
101 458 578 28 3.1 PHQ831_0055K402_0054 MB33 EZ703U 1805 1810 5087 29.82 1849/62 32 32 2600 2200 3800 61 400 98
9.2 Selection tables 9 PHQKright-angle planetary geared motors
266
