Stober PK - Page 267

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PHQ831K (n
1N
= 3000 rpm, M
2acc,max
= 2800 Nm)
101 458 578 28 3.1 PHQ831_0055K402_0054 MB33 EZ703U 1805 1810 5087 29.82 1849/62 45 32 2600 2200 3800 61 400 98
101 591 839 36 2.4 PHQ831_0055K402_0054 MB33 EZ705U 2680 2680 5087 29.82 1849/62 16 32 2600 2200 3800 73 400 103
101 591 839 36 2.4 PHQ831_0055K402_0054 MB33 EZ705U 2680 2680 5087 29.82 1849/62 24 32 2600 2200 3800 73 400 103
101 591 839 36 2.4 PHQ831_0055K402_0054 MB33 EZ705U 2680 2680 5087 29.82 1849/62 32 32 2600 2200 3800 73 400 103
101 591 839 36 2.4 PHQ831_0055K402_0054 MB33 EZ705U 2680 2680 5087 29.82 1849/62 45 32 2600 2200 3800 73 400 103
101 739 1338 45 1.9 PHQ831_0055K402_0054 MB43 EZ803U 2680 2680 5087 29.82 1849/62 50 65 2600 2200 3000 181 400 134
125 268 322 20 4.9 PHQ831_0055K402_0044 MB33 EZ702U 916 920 4224 24.00 24/1 16 15 2600 2200 3800 52 400 95
125 268 322 20 4.9 PHQ831_0055K402_0044 MB33 EZ702U 916 920 4224 24.00 24/1 24 15 2600 2200 3800 52 400 95
125 268 322 20 4.9 PHQ831_0055K402_0044 MB33 EZ702U 916 920 4224 24.00 24/1 32 15 2600 2200 3800 52 400 95
125 268 322 20 4.9 PHQ831_0055K402_0044 MB33 EZ702U 916 920 4224 24.00 24/1 45 15 2600 2200 3800 52 400 95
125 369 465 28 3.6 PHQ831_0055K402_0044 MB33 EZ703U 1453 1450 4224 24.00 24/1 16 32 2600 2200 3800 64 400 98
125 369 465 28 3.6 PHQ831_0055K402_0044 MB33 EZ703U 1453 1450 4224 24.00 24/1 24 32 2600 2200 3800 64 400 98
125 369 465 28 3.6 PHQ831_0055K402_0044 MB33 EZ703U 1453 1450 4224 24.00 24/1 32 32 2600 2200 3800 64 400 98
125 369 465 28 3.6 PHQ831_0055K402_0044 MB33 EZ703U 1453 1450 4224 24.00 24/1 45 32 2600 2200 3800 64 400 98
125 476 675 36 2.8 PHQ831_0055K402_0044 MB33 EZ705U 2235 2240 4224 24.00 24/1 16 32 2600 2200 3800 76 400 103
125 476 675 36 2.8 PHQ831_0055K402_0044 MB33 EZ705U 2235 2240 4224 24.00 24/1 24 32 2600 2200 3800 76 400 103
125 476 675 36 2.8 PHQ831_0055K402_0044 MB33 EZ705U 2235 2240 4224 24.00 24/1 32 32 2600 2200 3800 76 400 103
125 476 675 36 2.8 PHQ831_0055K402_0044 MB33 EZ705U 2235 2240 4224 24.00 24/1 45 32 2600 2200 3800 76 400 103
125 595 1077 45 2.2 PHQ831_0055K402_0044 MB43 EZ803U 2493 2490 5087 24.00 24/1 50 65 2600 2200 3000 184 400 134
125 595 1077 45 2.2 PHQ831_0055K402_0044 MB43 EZ803U 2493 2490 5087 24.00 24/1 72 65 2600 2200 3000 184 400 134
136 338 426 28 3.8 PHQ831_0055K402_0040 MB33 EZ703U 1332 1330 3872 22.00 22/1 16 32 2600 2200 3800 65 400 98
136 338 426 28 3.8 PHQ831_0055K402_0040 MB33 EZ703U 1332 1330 3872 22.00 22/1 24 32 2600 2200 3800 65 400 98
136 338 426 28 3.8 PHQ831_0055K402_0040 MB33 EZ703U 1332 1330 3872 22.00 22/1 32 32 2600 2200 3800 65 400 98
136 338 426 28 3.8 PHQ831_0055K402_0040 MB33 EZ703U 1332 1330 3872 22.00 22/1 45 32 2600 2200 3800 65 400 98
136 436 619 36 2.9 PHQ831_0055K402_0040 MB33 EZ705U 2049 2050 3872 22.00 22/1 16 32 2600 2200 3800 77 400 103
136 436 619 36 2.9 PHQ831_0055K402_0040 MB33 EZ705U 2049 2050 3872 22.00 22/1 24 32 2600 2200 3800 77 400 103
136 436 619 36 2.9 PHQ831_0055K402_0040 MB33 EZ705U 2049 2050 3872 22.00 22/1 32 32 2600 2200 3800 77 400 103
136 436 619 36 2.9 PHQ831_0055K402_0040 MB33 EZ705U 2049 2050 3872 22.00 22/1 45 32 2600 2200 3800 77 400 103
136 545 987 45 2.4 PHQ831_0055K402_0040 MB43 EZ803U 2421 2420 5087 22.00 22/1 50 65 2600 2200 3000 185 400 134
136 545 987 45 2.4 PHQ831_0055K402_0040 MB43 EZ803U 2421 2420 5087 22.00 22/1 72 65 2600 2200 3000 185 400 134
PHQ931K (n
1N
= 2000 rpm, M
2acc,max
= 5760 Nm)
45 1768 2674 48 2.1 PHQ931_0060K513_0073 MB43 EZ805U 5760 – 11250 44.08 1102/25 50 115 1900 1800 3000 280 771 173
PHQ931K (n
1N
= 3000 rpm, M
2acc,max
= 5760 Nm)
8.6 1380 1509 8.4 2.8 PHQ931_0060K513_0580 MB23 EZ501U 5136 – 11250 349.8 22736/65 8.0 8.0 3400 3000 4000 11 771 104
8.6 1509 1669 9.2 2.5 PHQ931_0060K513_0580 MB23 EZ402U 5136 – 11250 349.8 22736/65 8.0 8.0 3400 3000 4000 9.6 771 104
8.6 2215 2761 14 1.7 PHQ931_0060K513_0580 MB23 EZ404U 5760 – 11250 349.8 22736/65 8.0 8.0 3400 3000 4000 11 771 106
8.6 2376 2568 15 1.6 PHQ931_0060K513_0580 MB23 EZ502U 5760 – 11250 349.8 22736/65 8.0 8.0 3400 3000 4000 13 771 105
10 1140 1246 8.0 3.3 PHQ931_0060K513_0480 MB23 EZ501U 4243 – 11250 289.0 8091/28 8.0 8.0 3400 3000 4000 11 771 104
10 1140 1246 8.0 3.3 PHQ931_0060K513_0480 MB23 EZ501U 4243 – 11250 289.0 8091/28 12 8.0 3400 3000 4000 11 771 104
10 1246 1379 8.7 3.0 PHQ931_0060K513_0480 MB23 EZ402U 4243 – 11250 289.0 8091/28 8.0 8.0 3400 3000 4000 10 771 104
10 1246 1379 8.7 3.0 PHQ931_0060K513_0480 MB23 EZ402U 4243 – 11250 289.0 8091/28 12 8.0 3400 3000 4000 10 771 104
10 1830 2281 13 2.1 PHQ931_0060K513_0480 MB23 EZ404U 5760 – 11250 289.0 8091/28 8.0 8.0 3400 3000 4000 11 771 106
10 1830 2281 13 2.1 PHQ931_0060K513_0480 MB23 EZ404U 5760 – 11250 289.0 8091/28 12 8.0 3400 3000 4000 11 771 106
10 1962 2122 14 1.9 PHQ931_0060K513_0480 MB23 EZ502U 5760 – 11250 289.0 8091/28 8.0 8.0 3400 3000 4000 14 771 105
10 1962 2122 14 1.9 PHQ931_0060K513_0480 MB23 EZ502U 5760 – 11250 289.0 8091/28 12 8.0 3400 3000 4000 14 771 105
11 1030 1126 7.7 3.7 PHQ931_0060K513_0440 MB23 EZ501U 3833 – 11250 261.0 261/1 8.0 8.0 3400 3000 4000 11 771 104
11 1030 1126 7.7 3.7 PHQ931_0060K513_0440 MB23 EZ501U 3833 – 11250 261.0 261/1 12 8.0 3400 3000 4000 11 771 104
11 1126 1246 8.5 3.4 PHQ931_0060K513_0440 MB23 EZ402U 3833 – 11250 261.0 261/1 8.0 8.0 3400 3000 4000 10 771 104
11 1126 1246 8.5 3.4 PHQ931_0060K513_0440 MB23 EZ402U 3833 – 11250 261.0 261/1 12 8.0 3400 3000 4000 10 771 104
11 1653 2060 12 2.3 PHQ931_0060K513_0440 MB23 EZ404U 5760 – 11250 261.0 261/1 8.0 8.0 3400 3000 4000 11 771 106
11 1653 2060 12 2.3 PHQ931_0060K513_0440 MB23 EZ404U 5760 – 11250 261.0 261/1 12 8.0 3400 3000 4000 11 771 106
11 1773 1916 13 2.1 PHQ931_0060K513_0440 MB23 EZ502U 5760 – 11250 261.0 261/1 8.0 8.0 3400 3000 4000 14 771 105
11 1773 1916 13 2.1 PHQ931_0060K513_0440 MB23 EZ502U 5760 – 11250 261.0 261/1 12 8.0 3400 3000 4000 14 771 105
11 2323 2659 17 1.6 PHQ931_0060K513_0440 MB23 EZ503U 5760 – 11250 261.0 261/1 8.0 15 3400 3000 4000 17 771 107
11 3234 3833 24 1.2 PHQ931_0060K513_0440 MB23 EZ505U 5760 – 11250 261.0 261/1 8.0 15 3400 3000 4000 22 771 110
13 912 997 7.5 4.2 PHQ931_0060K513_0390 MB23 EZ501U 3395 – 11250 231.2 8091/35 8.0 8.0 3400 3000 4000 12 771 104
13 912 997 7.5 4.2 PHQ931_0060K513_0390 MB23 EZ501U 3395 – 11250 231.2 8091/35 12 8.0 3400 3000 4000 12 771 104
13 912 997 7.5 4.2 PHQ931_0060K513_0390 MB23 EZ501U 3395 – 11250 231.2 8091/35 16 8.0 3400 3000 4000 12 771 104
13 997 1103 8.1 3.8 PHQ931_0060K513_0390 MB23 EZ402U 3395 – 11250 231.2 8091/35 8.0 8.0 3400 3000 4000 10 771 104
13 997 1103 8.1 3.8 PHQ931_0060K513_0390 MB23 EZ402U 3395 – 11250 231.2 8091/35 12 8.0 3400 3000 4000 10 771 104
13 997 1103 8.1 3.8 PHQ931_0060K513_0390 MB23 EZ402U 3395 – 11250 231.2 8091/35 16 8.0 3400 3000 4000 10 771 104
13 1464 1825 12 2.6 PHQ931_0060K513_0390 MB23 EZ404U 5760 – 11250 231.2 8091/35 8.0 8.0 3400 3000 4000 12 771 106
13 1464 1825 12 2.6 PHQ931_0060K513_0390 MB23 EZ404U 5760 – 11250 231.2 8091/35 12 8.0 3400 3000 4000 12 771 106
13 1464 1825 12 2.6 PHQ931_0060K513_0390 MB23 EZ404U 5760 – 11250 231.2 8091/35 16 8.0 3400 3000 4000 12 771 106
