Objet30 User Guide 5 Using Objet Studio
DOC-34025 Rev. I 5-52
the future. objtf files are also useful when working from your company's
network, where the STL files are stored.
Note: Because the objtf file references the stl files used, they must remain in
the same file location as when the objtf file was saved.
To save the tray as an objtf file:
➢ In the Tray Settings tab, File group, click .
To open trays saved as objtf files, see "Opening Objet Tray Files" on page 5-
15.
OBJZF Files
To conveniently save all of the files as they are positioned on the build tray, for
storing the job, or for transferring it to another location, Objet Studio
compresses them into one objzf file. To later use the objzf file, the file must first
be expanded in Objet Studio and its component files saved.
Note: If you export an objzf file containing a stl file originally saved as read-
only, you cannot open (import) this objzf file to the folder where the read-only
stl file is saved.
To create an objzf file:
1. From the Objet Studio Commands menu , select Export Packed Job.
The Save As dialog box opens.
2. Select the folder, set the file name, and click Save.
Note: You can also export a print job as an objzf file from the Job Manager
screen—see "Additional Server Features" on page 5-77.
To open an objzf file:
➢ Double-click on the objtf file.
or—
1. From the Objet Studio Commands menu , select Import Packed Job.
2. In the Open dialog box, display the appropriate folder and select the file.
3. In the Browse for Folder dialog box, display the folder in which you want
Objet Studio to expand the compressed file, and click OK.
The objtf file and associated stl files are expanded and placed in the
selected folder, and the tray is displayed in Objet Studio.
