Objet30 User Guide 6 Operating and Maintaining the Printer
DOC-34025 Rev. I 6-12
When the weight of a cartridge drops below 100 grams, the printer alternates
the pumping of material between the heavier and the almost-empty cartridge.
This is indicated on the printer interface by an hour-glass icon. (See Figure 6-
10 on page 6-14.)
When a cartridge is completely empty, a trash icon is displayed.
Figure 6-9 Empty cartridge indicator
Printer Interface Color Key
The background colors in the printer indicator fields tell you at a glance
whether or not the value or item is suitable or ready for printing.
• Green—suitable/ready for printing
For example, in Figure 6-7 on page 6-10:
❒ Ambient—The ambient temperature of the printing chamber is within
the acceptable range.
❒ Heads Liquid—The level of Model and Support material in the
print-block reservoir is OK.
❒ Vacuum—The vacuum level in the system is within the acceptable
range.
