18 Installation Of Frequency Inverter
V560 Series High Performance Closed-Loop Vector Inverter User Manual
H1
W1
H
W
D
D
H
W
Type III suitable model: V560-4T2200G/4T2500P ~ V560-4T3150G/4T3500P
Type IV suitable model:
V560-4T3500G/4T4000P ~ V560-4T6300G/4T7000P
W Backboard width
W1 The distance between mounting hole
H The height of backboard
H1 The distance between mounting hole
D The distance between backboard and headboard
