Installation Of Frequency Inverter
V560 Series High Performance Closed-Loop Vector Inverter User Manual
19
Specific installation sizes of V560 series frequency inverters as listed below:
Model of frequency inverter
(Three-phase 380V)
W1
(
mm
)
W
(
mm
)
H1
(
mm
)
H
(
mm
)
D
(
mm
)
Specification
of screw
V560-4T0007G/4T0011P
87 97 152 162 130 M4
V560-4T0011G/4T0015P
V560-4T0015G/4T0022P
95 105 190 200 146 M4
V560-4T0022G/4T0030P
V560-4T0030G/4T0040P
121 135 234 248 175 M4
V560-4T0040G/4T0055P
V560-4T0055G/4T0075P
146 160 261 275 179 M5
V560-4T0075G/4T0090P
V560-4T0090G/4T0110P
169 180 290 305 179 M5
V560-4T0110G/4T0150P
V560-4T0150G/4T0185P
160 210 387 405 202 M6
V560-4T0185G/4T0220P
V560-4T0220G/4T0300P
160 250 422 445 216 M8
V560-4T0300G/4T0370P
V560-4T0370G/4T0450P
180 298 525 564 249 M8
V560-4T0450G/4T0550P
V560-4T0550G/4T0750P
260 350 564 606 277 M8
V560-4T0750G/4T0900P
293 400 685 725 271 M10
V560-4T0900G/4T1100P
V560-4T1100G/4T1320P
360 516 695 735 283 M10
V560-4T1320G/4T1600P
360 516 725 765 302 M10
V560-4T1600G/4T1850P
360 540 862 890 323 M10
V560-4T1850G/4T2000P
500 640 974 1000 323 M10
V560-4T2000G/4T2200P
V560-4T2200G/4T2500P
560 730 1073 1100 370 M10
V560-4T2500G/4T2800P
V560-4T2800G/4T3150P
600 756 1290 1322 410 M10
V560-4T3150G/4T3500P
V560-4T3500G/4T4000P
-- 900 -- 2100 600 --
V560-4T4000G/4T4500P
V560-4T4500G/4T5000P
-- 1000 -- 2100 600 --
V560-4T5000G/4T5600P
V560-4T5600G/4T6300P
-- 1200 -- 2100 600 --
V560-4T6300G/4T7000P
