Wiring Of Frequency Inverter
V260 Series High Performance Closed-Loop Vector Inverter User Manual
22
8) AC output reactor: When the wiring from the frequency inverter to the motor is longer (exceeding 20m), it
can restrict radio interference and leakage current.
9) Braking resistor: Improve the braking capacity of frequency inverter to avoid overvoltage failure when
slowing down.
The specification of recommended electric appliances is as follows:
Model of frequency
inverter
Adaptive motor (KW)
wire gauge
(major
loop) (mm
2
)
Air circuit
breaker (A)
Electromagn
etic contactor
(A)
General
loads
Load for fan and
water pump
V260-4T0007G/4T0011P 0.75 1.1 1. 10 9
V260-4T0011G/4T0015P 1.1 1.5 1.5 16 12
V260-4T0015G/4T0022P 1.5 2.2 2.5 16 12
V260-4T0022G/4T0030P 2.2 3.0 4 16 12
V260-4T0030G/4T0040P 3.0 4.0 4 20 16
V260-4T0040G/4T0055P 4.0 5.5 4 25 16
V260-4T0055G/4T0075P 5.5 7.5 6 32 22
V260-4T0075G/4T0090P 7.5 9.0 6 40 32
V260-4T0090G/4T0110P 9.0 11 10 50 32
V260-4T0110G/4T0150P 11 15 10 63 32
V260-4T0150G/4T0185P 15 18.5 10 63 38
V260-4T0185G/4T0220P 18.5 22 16 80 45
V260-4T0220G/4T0300P 22 30 16 100 63
V260-4T0300G/4T0370P 30 37 25 125 75
V260-4T0370G/4T0450P 37 45 25 160 85
V260-4T0450G/4T0550P 45 55 35 200 110
V260-4T0550G/4T0750P 55 75 50 225 140
V260-4T0750G/4T0900P 75 90 70 250 170
V260-4T0900G/4T1100P 90 110 70 315 205
V260-4T1100G/4T1320P 110 132 95 400 250
V260-4T1320G/4T1600P 132 160 95 400 330
V260-4T1600G/4T1850P 160 185 150 630 330
V260-4T1850G/4T2000P 185 200 150 630 400
V260-4T2000G/4T2200P 200 220 185 630 400
V260-4T2200G/4T2500P 220 250 185 800 500
V260-4T2500G/4T2800P 250 280 240 800 500
V260-4T2800G/4T3150P 280 315 240 1000 630
V260-4T3150G/4T3500P 315 350 300 1250 630
V260-4T3500G/4T4000P 350 400 300 1250 780
V260-4T4000G/4T4500P 400 450 400 1600 780
V260-4T4500G/4T5000P 450 500 400 1600 900
V260-4T5000G/4T5600P 500 560 450 1800 1000
V260-4T5600G/4T6300P 560 630 450 1800 1200
V260-4T6300G/4T7000P 630 700 500 1800 1300
