Wiring Of Frequency Inverter 23
V260 Series High Performance Closed-Loop Vector Inverter User Manual
Main loop screw specification/ tightening torque, as listed below
VFD model
Screw
specification
Tightening torque(N*m) Recommended lug model no
V260-4T0007G/4T0011P M3.5 0.7~0.9
PTV1.25-9
V260-4T0011G/4T0015P M3.5 0.7~0.9
PTV1.25-9
V260-4T0015G/4T0022P M3.5 0.7~0.9
PTV1.25-9
V260-4T0022G/4T0030P M3.5 0.7~0.9
PTV2-9
V260-4T0030G/4T0040P M4 1.2~1.5
RNY2-4S
V260-4T0040G/4T0055P M4 1.2~1.5
RNY2-4S
V260-4T0055G/4T0075P M4 1.2~1.5
RNY5.5-4S
V260-4T0075G/4T0090P M4 1.2~1.5
RNY5.5-4S
V260-4T0090G/4T0110P M4 1.2~1.5
RNY5.5-4S
V260-4T0110G/4T0150P M4 1.2~1.5
RNY5.5-4S
V260-4T0150G/4T0185P M5 2~2.5
RNY8-5S
V260-4T0185G/4T0220P M5 2~2.5
RNY8-5S
V260-4T0220G/4T0300P M6 4~6
RNY14-6
V260-4T0300G/4T0370P M6 4~6
RNY14-6
V260-4T0370G/4T0450P M8 9~11
T25-8
V260-4T0450G/4T0550P M8 9~11
T35-8
V260-4T0550G/4T0750P M8 9~11
T50-8
V260-4T0750G/4T0900P M10 18~23
T70-10
V260-4T0900G/4T1100P M10 18~23
T70-10
V260-4T1100G/4T1320P M10 18~23
T95-10
V260-4T1320G/4T1600P M10 18~23
T120-10
V260-4T1600G/4T1850P M10 18~23
T150-12
V260-4T1850G/4T2000P M10 18~23
T150-12
V260-4T2000G/4T2200P M12 25~30
T185-12
V260-4T2200G/4T2500P M12 25~30
T185-12
V260-4T2500G/4T2800P M12 25~30
2*T120-12
V260-4T2800G/4T3150P M16 40~50
T240-16
V260-4T3150G/4T3500P M16 40~50
T300-16
V260-4T3500G/4T4000P M12 25~30
2*T185-12
V260-4T4000G/4T4500P M12 25~30
2*T240-12
V260-4T4500G/4T5000P M12 25~30
2*T240-12
V260-4T5000G/4T5600P M12 25~30
4*T185-12
V260-4T5600G/4T6300P M16 40~50
4*T185-12
¾ The power of adaptive motor can be increased by one power grade when V260 series
frequency inverter is connected with loads for fans and water pumps compared with that
for connecting with general loads.
