Wiring Of Frequency Inverter
V260 Series High Performance Closed-Loop Vector Inverter User Manual
24
V260-4T6300G/4T7000P M16 40~50
4*T185-12
General control board/extension card connection terminal
General control terminal
Screw
specification
Tightening torque(N*m) Recommended lug model no
control board/extension
card terminal
M2 0.1~0.2 E0.5-6
control board/extension
card terminal
M3 0.3~0.4 E0.75-6
Lug model no E(mm) D(mm) d(mm) W(mm) B(mm) L(mm)
T
series
T25-8 8.3 9.1 6.7 13 13 32
T35-8 8.3 11 8.6 16.7 16 37
T50-8 8.3 12.4 9.5 18 17 41
T70-10 10.3 15 12 22.5 21.5 52.5
T95-10 10.3 17 13.4 25 22.5 55
T120-12 12.7 19 15 27 23 60
T150-12 12.7 21.2 16.5 30 27 67
T185-12 12.7 23 19 34 30 73
T240-12 12.7 26.5 21 38 38 91.5
T240-16 16.5 26.5 21 38 38 91.5
T300-16 16.5 30 24.5 43 42 98
Lug model no
d2(mm
)
W(mm
)
F(mm)
L(mm
)
H(mm) d1(mm)
D(mm
)
T(mm)
RNY
serie
s
RNY2-4S
4.3 6.6 7.9 22.2 11 2.3 4.8 0.8
RNY5.5-4
S
4.3 7.2 5.9 22.5 13 3.4 6.7 1
RNY8-5S
5.3 8.8 9.3 29.7 16 4.5 8 1.2
RNY14-6
6.5 16 14.5 43.5 21.5 5.4 11 1.4
Lug model no W(mm) F(mm) L(mm) H(mm) d1(mm) D(mm) T(mm)
PVT/E
series
PTV1.25-9
1.9 9 19 10 1.7 4.2 0.8
PTV2-9
1.9 9 19 10 2.3 4.7 0.8
