Wiring Of Frequency Inverter 31
V260 Series High Performance Closed-Loop Vector Inverter User Manual
Type IX major loop terminal Applicable type: V260-4T0750G/4T0900P ～ V260-4T2000G/4T2200P
R ST P-
E
UV
W
Ground
Three-phase power supply
Motor
P+
Braking unit
Type X major loop terminal Applicable type: V260-4T2200G/4T2500P ～ V260-4T3150G/4T3500P
R
P-E
U
VW
Ground
Motor
P+
Braking unit
Three-phase power supply
S
T
Type XI major loop terminal Applicable type: V260-4T3500G/4T4000P ～ V260-4T6300G/4T7000P
R
P-
U
VW
Motor
P+
Braking unit
Three-phase power supply
S
T
P
