PART NO. INDEX
CA-500 Series S/M A-4-3 Revised February 2004
19 TB200408
PART NO. PART DESCRIPTION UNIT Q'TY PAGE NO.
442-5475-1 TUBE TOALONE 3MMID X 6MMOD 10 A-1-5 1
442-5475-1 TUBE TOALONE 3MMID X 6MMOD 10 A-1-39 15
443-0823-8 CHAMBER NO. 4 1 A-1-5 26
443-0823-8 CHAMBER NO. 4 1 A-1-39 2
443-0823-8B CHAMBER NO.4 1 A-1-36 2
443-2804-4 NON-RETURN VALVE MFP-6-V 1 A-1-31 8
8
443-2804-4 NON-RETURN VALVE MFP-6-V 1 A-1-31 18
443-2804-4 NON-RETURN VALVE MFP-6-V 1 A-1-39 6
13
461-2047-7 OPERATOR'S MANUAL CA-500 1 A-1-33 1
13
461-2655-0 OPERATORS MANUAL CA-500 (2) 1 A-1-33 1
461-9128-7 TRAP CHAMBER PROCEDURE 1 A-1-39 18
541-1352-1 PUSH VIAL PV-10 10 A-1-33 7
5
662-0168-8 PCB NO. 6350 WITH ROM 1 A-1-5 29
662-0217-3 PCB NO.2132 (STANDARD) 1 A-1-11 1*#
662-0218-7 PCB NO.2132 (2 CIRCUITS) 1 A-1-11 3*
662-0219-1 PCB NO.2132 (3 CIRCUITS) 1 A-1-11 3#
662-0220-5 PCB NO.4086 1 A-1-9 7
662-0221-9 PCB NO.6362 1 A-1-5 19
662-0222-2 PCB NO.9264 1 A-1-17 4
662-0223-6 PCB NO.2134 1 A-1-7 2*#
662-0224-0 PCB NO.9260 1 A-1-9 12
662-0225-3 PCB NO.7015 1 A-1-5 25
662-0228-4 PCB NO.9265 1 A-1-25 3
662-0228-4 PCB NO.9265 1 A-1-27 3
5
662-0276-3 PCB NO. 6350 WITH ROM (FOR CA) 1 A-1-5 29
8
662-0278-1 PCB NO.7015 (2)(FLASH MEMORY) 1 A-1-5 25
17
662-0279-4 D-DIMER LED ASSY (800NM) 1 A-1-11 7$
662-0280-9 D-DIMER LED ASSY (575NM) 1 A-1-11 7&
662-0281-2 PCB NO.2156 (STANDARD CLOT/AT3) 1 A-1-11 1*#
662-0282-6 PCB NO.2156 (2 CIRCUITS CLOT) 1 A-1-11 3*
17
662-0283-0 PCB NO.2156 (3 CIRCUITS AT3/DD) 1 A-1-11 3#&$
17
662-0284-3 PCB NO.2156 (4 CIRCUITS DD 800NM) 1 A-1-11 1$
662-0285-7 PCB NO.2156 (5 CIRCUITS DD 575NM) 1 A-1-11 1&
8
662-0286-1 PCB NO.2157 1 A-1-7 2*#&
8
662-0287-4 PCB NO.6373 1 A-1-5 19
8
662-0288-8 PCB NO. 6375 ASSY 1 A-1-5 29
8
662-0289-1 PCB NO.9303 1 A-1-25 3
662-2203-9 DETECTOR THERMAL ASSY 1 A-1-11 4
662-2203-9 DETECTOR THERMAL ASSY 1 A-1-35 20
17
662-2204-2 CHROMOGENIC LED ASSY 1 A-1-11 6#&$
662-2204-2 CHROMOGENIC LED ASSY 1 A-1-35 22
662-2205-6 COAGULATION LED ASSY 1 A-1-11 2
662-2205-6 COAGULATION LED ASSY 1 A-1-35 23
662-2206-0 COOLER THERMAL ASSY (SERNSOR IC) 1 A-1-13 3
662-2206-0 COOLER THERMAL ASSY 1 A-1-35 2
662-2207-3 THERMAL SENSOR ASSY 1 A-1-9 13
662-2207-3 THERMAL SENSOR ASSY 1 A-1-35 1
662-2208-7 TRANSFORMER POWER ASSY (200V) 1 A-1-5 6#
662-2209-1 TRANSFORMER POWER ASSY (100V) 1 A-1-5 6$¥
662-2219-8 POWER SWITCH ASSY CA-500 1 A-1-3 5
662-2220-2 RINSE BOTTLE FLOAT SWITCH ASSY (2L) 1 A-1-31 1
662-2221-6 WASTE BOTTLE FLOAT SWITCH ASSY (2L) 1 A-1-31 21
8
662-2409-1 RINSE BOTTLE FLOAT SWITCH ASSY (5L) 1 A-1-31 11
8
662-2410-6 WASTE BOTTLE FLOAT SWITCH ASSY (5L) 1 A-1-31 31
662-8181-6 ID WIRING CORD 1 A-1-3 12
662-8181-6 ID WIRING CORD 1 A-1-35 7
