PART NO. INDEX
CA-500 Series S/M A-4-4 Revised February 2004
19 TB200408
PART NO. PART DESCRIPTION UNIT Q'TY PAGE NO.
662-8182-0 X AXIS WIRING CORD 1 A-1-9 11
662-8182-0 X AXIS WIRING CORD 1 A-1-35 12
662-8214-1 WIRING CORD PD DW0458 1 A-1-11 10
8
662-8222-1 WIRING CORD PD SIGNAL DW0590 1 A-1-35 34
663-0158-8 DETECTOR BLOCK (AT3) 1 A-1-9 4#
663-0158-8 DETECTOR BLOCK (AT3) 1 A-1-11 1-6#
663-0159-1 DETECTOR BLOCK (STANDARD) 1 A-1-9 4*
663-0159-1 DETECTOR BLOCK (STANDARD) 1 A-1-11 1-5*
663-0160-6 HEATER ASSY 1 A-1-11 5
663-0160-6 HEATER ASSY 1 A-1-35 21
663-0161-0 COOLING SECTION ASSY 1 A-1-9 1
663-0161-0 COOLING SECTION ASSY 1 A-1-13 1-
B
663-0162-3 COOLER ASSY (THERMAL MODULE) 1 A-1-13 1
663-0162-3 COOLER ASSY 1 A-1-35 4
14
663-0163-7 COOLING FAN ASSY 1 A-1-13 2
663-0163-7 COOLING FAN ASSY 1 A-1-35 3
663-0164-1 VOLUMETRIC PISTON ASSY 1 A-1-5 21
663-0164-1 VOLUMETRIC PISTON ASSY 1 A-1-21 1-
663-0165-4 SYRINGE MOTOR ASSY 1 A-1-23 1
663-0165-4 SYRINGE MOTOR ASSY 1 A-1-35 28
663-0166-8 CYLINDER ASSY 1 A-1-21 1
663-0166-8 CYLINDER ASSY 1 A-1-21 11-
663-0167-1 PISTON ASSY 1 A-1-21 2
663-0168-5 OPERATION PANEL ASSY 1 A-1-3 3
663-0168-5 OPERATION PANEL ASSY 1 A-1-25 1-
663-0168-5 OPERATION PANEL ASSY 1 A-1-27 1-
663-0169-9 VR ASSY 1 A-1-27 4
663-0169-9 VR ASSY 1 A-1-35 25
663-0170-3 OPERATION PANEL BASE ASSY 1 A-1-27 1
663-0171-7 EMERGENCY STOP SW ASSY 1 A-1-27 2
663-0171-7 EMERGENCY STOP SW ASSY 1 A-1-35 26
663-0172-1 PRINTER ASSY 1 A-1-25 2
663-0173-4 SAMPLE TABLE ASSY (STANDARD) 1 A-1-3 4*
663-0174-8 SAMPLE TABLE ASSY (ID) 1 A-1-3 4#
2
663-0175-1 SAMPLE TABLE BASE ASSY 1 A-1-3 10
19
663-0175-1 SAMPLE TABLE BASE ASSY 1 A-1-38 4
663-0176-5 ID MOTOR ASSY 1 A-1-3 11
663-0176-5 ID MOTOR ASSY 1 A-1-35 8
2
663-0177-9 ID ASSY 1 A-1-3 10
663-0177-9 ID ASSY 1 A-1-35 9
663-0179-6 SAMPLE RACK SENSOR ASSY 1 A-1-3 7
663-0179-6 SAMPLE RACK SENSOR ASSY 1 A-1-35 6
663-0180-1 DRIVE ARM ASSY 1 A-1-7 1
663-0181-4 X AXIS SLIDER ASSY 1 A-1-7 3
663-0181-4 X AXIS SLIDER ASSY 1 A-1-15 11-
663-0182-8 Z AXIS BASE ASSY 1 A-1-17 1-
663-0183-1 PIPETTE HOLDER ASSY 1 A-1-17 1
663-0183-1 PIPETTE HOLDER ASSY 1 A-1-19 11-
663-0184-5 PIPETTE CRUSH SENSOR ASSY 1 A-1-19 11
663-0185-9 Y AXIS MOTOR ASSY 1 A-1-15 11
663-0185-9 Y AXIS MOTOR ASSY 1 A-1-35 15
663-0186-2 Z AXIS MOTOR ASSY 1 A-1-17 3
663-0186-2 Z AXIS MOTOR ASSY 1 A-1-35 16
663-0187-6 MIXER MOTOR ASSY 1 A-1-19 2
663-0187-6 MIXER MOTOR ASSY 1 A-1-35 19
663-0188-0 CATCHER ASSY 1 A-1-17 2
