SYSMEX CA-500 - Page 228

PART NO. INDEX
CA-500 Series S/M A-4-5 Revised February 2004
19 TB200408
PART NO. PART DESCRIPTION UNIT Q'TY PAGE NO.
663-0188-0 CATCHER ASSY 1 A-1-19 1-
663-0189-3 TUBING ASSY (PIPETTE) 1 A-1-17 6
663-0190-8 PIPETTE ASSY CA-500 1 A-1-19 12
663-0190-8 PIPETTE ASSY CA-500 1 A-1-35 17
663-0191-1 PRESSURE PUMP ASSY 1 A-1-5 22
663-0191-1 PRESSURE PUMP ASSY 1 A-1-35 29
663-0195-6 AC INLET ASSY 1 A-1-5 20
663-0196-0 MAIN UNIT FAN ASSY 1 A-1-5 23
663-0196-0 MAIN UNIT FAN ASSY 1 A-1-35 10
663-0197-3 VACUUM PUMP ASSY 1 A-1-5 9
663-0197-3 VACUUM PUMP ASSY 1 A-1-35 32
663-0198-7 SOLENOID VALVE ASSY (VOLUMET.) 1 A-1-5 14
663-0198-7 SOLENOID VALVE ASSY (VOLUMET.) 1 A-1-35 30
663-0199-1 RINSING CUP ASSY 1 A-1-9 3
663-0200-8 SOLENOID ASSY 1 A-1-15 1
663-0200-8 SOLENOID ASSY 1 A-1-35 5
663-0201-1 X AXIS MOTOR ASSY 1 A-1-9 6
663-0201-1 X AXIS MOTOR ASSY 1 A-1-35 13
663-0202-5 REAGENT STAGE ASSY 1 A-1-3 1
8
663-0203-9 SAMPLE STAGE ASSY 1 A-1-3 2&
8
663-0204-2 LIGHT SHIELD COVER ASSY 1 A-1-3 13&
663-0205-6 PRINTER COVER ASSY 1 A-1-3 9
663-0206-0 REAGENT RACK ASSY 1 A-1-33 9
663-0207-3 REACTION TUBE TRASH BOX 1 A-1-33 10
663-0209-1 RINSE BOTTLE ASSY CA-5H (2L) 1 A-1-31 1-8*
663-0209-1 RINSE BOTTLE ASSY CA-5H (2L) 1 A-1-33 2*
663-0209-1 RINSE BOTTLE ASSY CA-500 1 A-1-35 33
663-0210-5 WASTE BOTTLE ASSY CA-5H (2L) 1 A-1-31 21-26*
663-0210-5 WASTE BOTTLE ASSY CA-5H (2L) 1 A-1-33 6*
663-0210-5 WASTE BOTTLE ASSY 1 A-1-35 24
663-0211-9 TRAP CHAMBER COMPLETE 1 A-1-33 3
663-0212-2 SAMPLE TUBE SPACER 10MM DIAMET 1 A-1-33 OPTION
663-0213-6 SAMPLE TUBE SPACER 13 PHI 1 A-1-33 8
663-0217-1 TABLE LOCK MECHANISM ASSY 1 A-1-9 2
663-0217-1 TABLE LOCK MECHANISM ASSY 1 A-1-15 1-
A B
663-0370-4 PULLEY 1329A 1 A-1-7 6
A 14
663-0371-8 SHAFT-B DM1090B 1 A-1-7 5
C
663-0372-1 HEAT SINK DM1113 1 A-1-13 6
663-0373-5 TOP PANEL DM0930 1 A-1-37 1
14
663-0374-9 BASE DM1197B 1 A-1-7 4
663-0375-2 PANEL (R) DM0932 1 A-1-37 2
B
663-0392-6 PULLEY DM1329 1 A-1-7 6
2
663-0393-0 Z1 SLIDER-C ASSY DU1469 1 A-1-17 10
2
663-0394-3 Z2 SLIDER-C ASSY DU1468 1 A-1-17 11
8
663-0399-1 DETECTOR BLOCK (D-DIMER) 1 A-1-9 4&
663-0399-1 DETECTOR BLOCK (D-DIMER) 1 A-1-11 1-8&
8
663-0400-9 SAMPLE STAGE ASSY 2 (IMMUNO) 1 A-1-3 2%
8
663-0401-2 LIGHT SHIELD COVER ASSY (IMMUNO) 1 A-1-3 13%
8
663-0402-6 RINSE BOTTLE ASSY CA-5H (5L) 1 A-1-31 11-18*
663-0402-6 RINSE BOTTLE ASSY CA-5H (5L) 1 A-1-33 2#
8
663-0403-0 WASTE BOTTLE ASSY CA-5H (5L) 1 A-1-31 31-36*
663-0403-0 WASTE BOTTLE ASSY CA-5H (5L) 1 A-1-33 6#
17
663-0404-3 CH6 10 A-1-11 8&$
8
663-0405-7 RINSE BOTTLE ASSY CA-5H (5L/EU/UK) 1 A-1-31 11-18#
663-0405-7 RINSE BOTTLE ASSY CA-5H (5L/EU/UK) 1 A-1-33 2#
10
663-0406-1 WASTE BOTTLE ASSY CA-5H (5L/EU/UK) 1 A-1-31 31-36#
