Configuration
Topcon HiPer+ Operator’s Manual
2-36
Figure 2-31. PDL Radio Link Tab
NOTICE
The Base and internal HiPer+ (Rover) PDL
radios must be configured with the same
Channels, Radio Link characteristics (except
Digisquelch) and Serial Interface parameters.
11. Click the Serial Interface tab and set the following
parameters (Figure 2-32 on page 2-37):
• Baud Rate – 38400
• Parity – None
NOTICE
Parity should always be set to None.
• Mode – Transparent w/EOT Timeout
