CHAPTER 4 TRANSMISSION SEQUENCE

B-EP Series

4-38

4.3.3.3 GRAPHIC DATA STORE COMMAND

When transmission is cancelled while graphic data is transmitted from the application, the data

cannot be properly stored because data subsequently transmitted is recognized as a graphic

command unless the graphic data has been transmitted before the transmission is cancelled.

If communication is interrupted while graphic data is transmitted, it is necessary to transmit

graphic data for the number of bytes that was not transmitted as dummy data, turn off and on the

power of the printer, or reset the printer.

[Command transmission and storage results (Examples)]

(1) When transmitting graphic storage data as usual,

[1B][53][47][3B][31][2C][30][30][34][30][2C][30][30][34][30]

[2C][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF] 1st label data

[FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF][FF]

[FF][FF][FF][FF][FF][FF][0A][00][0D][0A]

[1B]XO;01,1[0A][00]

[1B]D0630,0480,0600[0A][00]

[1B]PC00;0030,0050,2,2,A,00,B,00,1,0[0A][00]

[1B]PC00;0030,0350,2,2,A,00,B,00,1,0[0A][00]

[1B]N;1,0150,0100[0A][00]

[1B]N;2,0150,0400[0A][00]

[1B]XP[0A][00]

[1B]X[01][21][01]Graphic Data No. 1[0A]

Graphic Data No. 2[0A][00]

Storage result: Data is properly stored.
