CHAPTER 4 TRANSMISSION SEQUENCE
B-EP Series
4-4
4.2.2 LABEL ISSUE OPERATION
An example of the label issue operation is described below.
(1) Where the Saved Data Read Command is not used:
NOTES: (1) The Label Size Set Command must be sent.
(2) After the power is turned off then on, the Bit Map Font Format Command, the
Outline Font Format Command, and the Barcode/Two-dimensional Code Format
Command should be sent as the occasion arises, because they are not protected
in memory.
Bit Map Font Data Command
<Change data issue>
Yes
Position Fine Adjust Command
Print Density Fine
d
ust Command
Image Buffer Clear Command
Line Format Command
Bit Map Font Format Command
Outline Font Format Command
Barcode/2-D Code Format Command
[ESC] D: Sets the label size.
[ESC] AX: Adjusts the feed length.
[ESC] AY: Adjusts the print density/separation setting.
[ESC] C: Clears the image buffer.
[ESC] LC: Sets the line format and draws it.
[ESC] PC: Sets the bit map font format.
[ESC] PV: Sets the outline font format.
[ESC] XB: Sets the barcode/2-D code format.
[ESC] RC: Draws bit map font data.
Feed Command
[ESC] T: Feeds one sheet of paper and aligns it
with the first print position.
Outline Font Data Command
[ESC] RV: Draws outline font data.
Barcode/2-D Code Data Command
[ESC] RB: Draws barcode/2-D code data.
Issue Command
[ESC] XS: Issues (prints) the label.
No
<Format change>
Yes
No
<Label change>
Yes
No
Power OFF
Label Size Set Command
Place paper
Mode Select Command
[ESC] M: Changes the print mode.
Power ON or
After linking to each interface
