CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-211
5.16.2 BLUETOOTH RELATED PARAMETER ACQUIRE COMMAND [ESC] WT
Function Acquires the parameters related to the Bluetooth.
Format [ESC] WT [LF] [NUL]
Explanation (1) This command reads the parameters related to the Bluetooth. When using the
IrDA: TEC Protocol, the following information field is placed in the information
frame and sent in packets to the host.
[Information field to be sent when IrDA: TEC Protocol is used]
STX Sec Inq Interval Window
02H 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH
Inquiry/page window
0018 to 4096
Inquiry/page interval
0018 to 4096
Inquiry timer
0 (30H): Inquiry is not possible.
1 (31H): Inquiry is possible only within 60 seconds after a printer power on
2 (32H): Inquiry is possible at anytime.
Security setting
1 (31H): No security
2 (32H): No security
3 (33H): Link level security is effective
Bluetooth device name CRC
32 bytes xxH xxH
Bluetooth device name: Fixed at 32 bytes
When the Bluetooth device name is “TOSHIBATEC BT,”
[54H] [4FH] [53H] [48H] [49H] [42H] [41H] [20H] [54H] [45H] [43H] [20H] [42H] [54H] [00H] [00H]
T O S H I B A ‘ ‘ T E C ‘ ‘ B T
[00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H]
* When the Bluetooth device name is less than 32 bytes, the remaining bytes are filled with 00H.
[Information field to be sent when IrDA: IrCOMM, IrDA: IrOBEX, USB, RS-232C, Bluetooth, or
wireless LAN is used]
SOX STX Sec Inq Interval Window
01H 02H 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH
Bluetooth device name ETX EOT CR LF
32 bytes 03H 04H 0DH 0AH
To Next Page
