CHAPTER 6 LABEL MODE (INTERFACE COMMANDS)
B-EP Series
6-55
6.6 COMMANDS RELATED TO ISSUE AND FEED
6.6.1 DATA PRINT COMMAND X
Function Draws or prints the data.
Format [IrDA: TEC Protocol]
Xabcddd --- eee --- nnn ---
[IrDA: IrCOMM, IrDA: IrOBEX, USB, RS-232C, Bluetooth, Wireless LAN]
[ESC] Xabcddd --- eee --- nnn --- [NUL]
Term a: Form No.
01H to 14H (1 to 20)
Selection of the reprint key function (Firmware V1.1 or greater)
0: Enabled
1: Disabled
When the form No. is 81H to 8AH (1 to 10) and if an error occurs during
printing, the reprint key will be enabled until a label is successfully issued.
When the form No. is 8BH to 94H (11 to 20), the reprint key will be disabled
if an error occurs during printing.
b: Sensor designation and ACK (IrDA: TEC Protocol) /status transmission (IrDA:
IrCOMM, IrDA: IrOBEX, USB, RS-232C, Bluetooth) to notify the issue end
00H: Transmissive sensor, No ACK/status transmission
01H: Transmissive sensor, ACK/status transmission
10H: Reflective sensor, No ACK/status transmission
11H: Reflective sensor, ACK/status transmission
20H: No sensor designation, No ACK/status transmission
21H: No sensor designation, ACK/status transmission
c: No. of labels to be issued
01H to FFH (1 to 255)
Even in the strip issue mode, the designated number of labels is printed.
ddd ---: Data of character/barcode/2-D code No. 00
eee ---: Data of character/barcode/2-D code No. 01
nnn ---: Data of character/barcode/2-D code No. nn
When a delimiter is required, it
should be added to the end of
data. (Refer to “Explanation.”)
7 6 5 4 3 2 1 0
Form No. (Bit 0 to Bit 6) 01H to 14H (1 to 20)
Reprint key enabled or disabled (Bit 7)
To Next Page
