Page #238 background imageLoading...
Page #238 background image
CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-68
5.6.4 BARCODE FORMAT COMMAND [ESC] XB
~ In the case of WPC, CODE93, CODE128, UCC/EAN128, EAN128, Customer Barcode,
POSTNET, RM4SCC, KIX CODE
Function Sets the format to indicate where and how the barcode is to be printed and how it is to
be printed.
(WPC is the generic name for barcodes of JAN, EAN and UPC.)
Format c [ESC] XBaa; bbbb, cccc, d, e, ff, k, llll (, mnnnnnnnnnn, ooo, p, qq)
(= sss ------ sss) [LF] [NUL]
d [ESC] XBaa; bbbb, cccc, d, e, ff, k, llll (, mnnnnnnnnnn, ooo, p, qq)
(; tt
1
, tt
2
, tt
3
, ------, tt
20
) [LF] [NUL]
Term aa: Barcode number
00 to 31
bbbb: X-coordinate of the print origin of barcode
Fixed at 4 digits (in 0.1 mm units)
cccc: Y-coordinate of the print origin of barcode
4 or 5 digits (in 0.1 mm units)
d: Type of barcode
Compatible mode for the B-SP
series: OFF
Compatible mode for the B-SP
series: ON
0: JAN8, EAN8
5: JAN13, EAN13
6: UPC-E
7: EAN-13 + 2digits
8: EAN-13 + 5digits
9: CODE128 (with auto code selection)
A: CODE128 (without auto code selection)
C: CODE93
G: UPC-E + 2 digits
H: UPC-E + 5 digits
I: EAN-8 + 2 digits
J: EAN-8 + 5 digits
K: UPC-A
L: UPC-A + 2 digits
M: UPC-A + 5 digits
N: UCC/EAN128 N: EAN128
R: Customer barcode (Postal code for Japan)
S: Highest priority customer barcode (Postal code for Japan)
U: POSTNET (Postal code for U.S.A.)
V: RM4SCC (ROYAL MAIL 4 STATE CUSTOMER CODE) (Postal code for U.K.)
W: KIX CODE (Postal code for Belgium)
