CHAPTER 16 BARCODE/TWO-DIMENSIONAL CODE TABLE
B-EP Series
16-13
16.12 DATA MATRIX
16.12.1 FORMAT ID
The code to be used is designated using the format ID.
Format ID Code Details
1 Numerics 0 to 9 space
2 Letters A to Z space
3 Alphanumerics, symbols 0 to 9 A to Z space . , - /
4 Alphanumerics 0 to 9 A to Z space
5 ASCII (7-bit) 00H to 7FH
6 ISO (8-bit) 00H to FFH (Kanji)
16.12.2 TRANSFER CODE
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 NUL DLE SP 0 @ P ` p
1 SOH DC1 ! 1 A Q a q
2 STX DC2 ” 2 B R b r
3 ETX DC3 # 3 C S c s
4 EOT DC4 $ 4 D T d t
5 ENQ NAK % 5 E U e u
6 ACK SYN & 6 F V f v
7 BEL ETB ’ 7 G W g w
8 BS CAN ( 8 H X h x
9 HT EM ) 9 I Y i y
A LF SUB * : J Z j z
B VT ESC + ; K [ k {
C FF FS , < L \ l |
D CR GS – = M ] m }
E SO RS . > N ^ n ~
F SI US / ? O _ o
16.12.3 HOW TO TRANSMIT THE CONTROL CODE DATA
NUL (00H) → > @ (3EH, 40H)
SOH (01H) → > A (3EH, 41H)
STX (02H) → > B (3EH, 42H)
Ú
GS (1DH) → > ] (3EH, 5DH)
RS (1EH) → > ^ (3EH, 5EH)
US (1FH) → > _ (3EH, 5FH)
16.12.4 HOW TO TRANSMIT THE SPECIAL CODES
> (3EH) → > 0 (3EH, 30H)
16.12.5 HOW TO TRANSMIT THE KANJI CODES
• Shift JIS
• JIS hexadecimal
(For details, refer to the section for the Barcode Data Command.)
