CHAPTER 16 BARCODE/TWO-DIMENSIONAL CODE TABLE
B-EP Series
16-21
16.15.2 When the MaxiCode specification is set to “TYPE2: Special specification” in the system
mode:
[Transfer Code for MaxiCode]
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 NUL DLE SP 0 @ P ` p
1 SOH DC1 ! 1 A Q a q
2 STX DC2 ” 2BRbr
3 ETX DC3 # 3CScs
4 EOT DC4 $ 4DTdt
5 ENQ NAK % 5 E U e u
6 ACK SYN & 6 F V f v
7 BEL ETB ’ 7 G W g w
8 BS CAN ( 8HXhx
9 HT EM ) 9I Yi y
A
LF
(
Note1
)
SUB * : J Z j z
B VT ESC + ; K [ k {
C FF FS , < L \ l |
D CR GS - = M ] m }
E SO RS . >N^n~
F SI US / ? O _ o DEL
(Note2)
The all codes (00H to FFH) can be used. In the following cases, however, the codes will
become special codes. For the transfer method, refer to the following:
Note 1: In case of LF (0AH) data:
LF (0AH) → J (FFH, 4AH)
Note 2: In case of (FFH) data:
(FFH) → (FFH, FFH)
ESC (1BH) and NUL (00H) can be used as they are.
To Next Page
