CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-147
5.7.2 OUTLINE FONT DATA COMMAND [ESC] RV
Function Provides data for the outline font row.
Format c [ESC] RVaa; bbb ------- bbb [LF] [NUL]
d Link Field Data Command
[ESC] RV; ccc --- ccc [LF] ddd --- ddd [LF] ------- [LF] xxx --- xxx [LF] [NUL]
Term aa: Character string number
00 to 99
bbb ------- bbb: Data string to be printed
Max. 255 characters
Any excess data will be discarded.
For character codes, refer to the character code table mentioned later.
ccc ------- ccc: Data string of link field No. 1
ddd ------- ddd: Data string of link field No. 2
Ú
xxx ------- xxx: Data string of link field No. 99
Explanation
(1) Link field data string
• After the link field No. is designated using the Format Command, the data strings are
linked by the Link Field Data Command to draw an image.
• Up to 255 characters of data strings can be linked. However, when the font type is C,
up to 127 characters can be linked.
When the number of characters exceeds the maximum number of digits, the excess data
will be discarded.
• Up to 99 data strings can be linked.
• Up to 2048 bytes can be used as the command length ([ESC] to [NUL]) of the Link Field
Data Command.
• When the data string is omitted using the Link Field Data Command, the following
process is performed:
c No process will be performed for the field which contains no print data due to the
omission.
d When the field partially loses print data due to the omission, the only remaining data
will be processed as print data.
• The Link Field Data Command can be used for the bit map font fields, outline font fields
and barcode fields.
• (The same result is obtained when any of the “RC,” “RV” or “RB” command code is
designated.)
Refer to Outline Font Format Command ([ESC] PV)
To Next Page
