Page #606 background imageLoading...
Page #606 background image
CHAPTER 8 ESC/POS MODE (INTERFACE COMMANDS)
B-EP Series
8-79
8.10.54 DOWNLOADED BIT IMAGE PRINT MODE SET COMMAND [GS] /
Function Prints a logo (image data) specified by n in mode specified by k
Format [GS] /m
Term ASCII: GS /
Hex: 1Dh 2Fh
[Parameter]
m: Downloaded bit image data print mode 0 m 3 (00h m 03h)
or
48 m 51 (30h m 33h)
0,48 Normal mode
1,49 Double-width mode
2,50 Double-height mode
3,51 Quadruple mode
Explanation (1) Unless downloaded bit image data is defined, this command will be ignored.
(2) When standard mode is selected, the command will be valid only if no data is
present in the print buffer.
(3) Inverted printing, bold printing, double printing, underlining, character size, or
reversed printing will become invalid even if specified.
(4) If there is a line where the print area specified by the Left Margin Set Command
([GS] L) or Print Area Width Set Command ([GS] W) does not reach the minimum
width in bit image mode (1 dot in normal or double-height mode, or 2 dots in
double-width or quadruple mode), the print area will be extended to the right until it
reaches the minimum width in bit image mode to the extent that the printable area is
not exceeded. This only applies to such a line.
Reference Downloaded Bit image Define Command ([GS] *)
