CHAPTER 6 LABEL MODE (INTERFACE COMMANDS)
B-EP Series
6-75
6.13 COMMANDS RELATED TO STATUS
6.13.1 STATUS REQUEST COMMAND [ESC] FM, [ESC] WS, [ESC] V
Function Sends the printer status to the host computer.
Format [ESC] WS [LF] [NUL]
[ESC] FM [LF] [NUL]
[ESC] v
Explanation (1) When receiving this command, the printer sends the printer status and battery
status to the host.
For IrDA: TEC Protocol: Data to be sent (Fixed at 27 bytes)
STX Printer ID Version No. of each form Printer status Battery status CRC
02H xxH xxH V01 V02 ········· V20 xxH xxH xxH xxH
For IrDA: IrCOMM, IrDA: IrOBEX, USB, RS-232C, Bluetooth, Wireless LAN:
Data to be sent (Fixed at 5 bytes)
STX Printer ID Printer status Battery status
02H xxH xxH xxH xxH
Printer ID ............... 2-byte hex data (in order from High to Low)
Printer status ......... Printer status is indicated in 1-byte data.
00H: Normal status (Idling)
01H: Cover open state
02H: Command syntax error (including Ir packet error)
03H: Paper jam
04H: Label end
05H: Cover open error
06H: Broken thermal head dots error
07H: Thermal head excessive temperature
08H: Flash ROM write error
09H: Flash ROM erase error
0AH: Low battery (Print failure)
0BH: Operating
0DH: Normal end + Label end (See NOTE.)
0EH: Flash ROM storage area full state
0FH: Wait for strip
(10H: Normal issue end):
Response status for automatic status transmission
14H: Pause state
19H: Ambient temperature error
32H: Abnormal battery temperature
33H: Battery excessive temperature
37H: Charging error
39H: Bluetooth setup error (including initialiation error)
45H: Wait for battery recovery
46H: Wait for print head temperature reduction
47H: Wait for motor temperature reduction
55H: Writable character/PC command save mode
