CHAPTER 11 OTHER FUNCTIONS
B-EP Series
11-7
11.11.2 STATUS FORMAT
• TPCL Mode
[IrDA: TEC Protocol]
STX ID ID Status Remaining count CRC CRC
01H XXH XXH 3XH 3XH 3XH 3XH 3XH 3XH 3XH XXH XXH
[IrDA: IrCOMM, IrDA: IrOBEX, USB, RS-232C, Bluetooth, or wireless LAN interface]
SOH STX Status Remaining count ETX EOT CR LF
01H 02H 3XH 3XH 3XH 3XH 3XH 3XH 3XH 03H 04H 0DH 0AH
● LABEL, RECEIPT, or ESC/POS Mode
[IrDA: TEC Protocol] Data to be transmitted (fixed at 27 bytes)
STX Printer ID Version No. of each form Printer status Battery status CRC
02H xxH xxH V01 V02
･････････
V20 xxH xxH xxH xxH
[IrDA :IrCOMM, IrDA: IrOBEX, USB, RS-232C, Bluetooth, or wireless LAN interface]
Data to be transmitted (fixed at 5 bytes)
STX Printer ID Printer status Battery status
02H xxH xxH xxH xxH
Printer ID : 2-byte hex data (from High to Low)
Printer status : 1-byte data representing the printer status
Battery status : A battery charging condition is represented in 5 levels.
CRC : 2-byte hex data(from Low to High)
Remaining count
• 0000 to 9999
(Fixed at 0000 in the save mode)
Type of status
• “1” (31H) (In response to a Status Request Command)
• “2” (32H) (Automatic status transmission)
Detail status
Remaining count
• 0000 to 9999
(Fixed at 0000 in the save mode)
Type of status
• “1” (31H) (In response to a Status Request Command)
• 2” (32H) (Automatic status transmission)
Detail status
