CHAPTER 6 LABEL MODE (INTERFACE COMMANDS)
B-EP Series
6-88
6.14.2 BLUETOOTH RELATED PARAMETER ACQUIRE COMMAND [ESC] WT
Function Acquires the parameter settings related to the Bluetooth.
Format [ESC] WT [LF] [NUL]
Explanation (1) This command reads the parameters related to the Bluetooth. When using the
IrDA, the following information field is placed in the information frame and sent to
the host.
[Information field to be sent when IrDA: TEC Protocol is used]
STX Sec Inq Interval Window
02H 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH
Inquiry/page window
0018 to 4096
Inquiry/page interval
0018 to 4096
Inquiry timer
0 (30H): Inquiry is not possible.
1 (31H): Inquiry is possible only within 60 seconds after a
printer power on
2 (32H): Inquiry is possible at anytime.
Security setting
1 (31H): No security
2 (32H): No security
3 (33H): Link level security is effective
Bluetooth device name CRC
32 bytes xxH xxH
Bluetooth device name: Fixed at 32 bytes.
When the Bluetooth device name is “TOSHIBA TEC BT.”
[54H] [4FH] [53H] [48H] [49H] [42H] [41H] [20H] [54H] [45H] [43H] [20H] [42H] [54H] [00H] [00H]
T O S H I B A ‘ ’ T E C ‘ ’ B T
[00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H] [00H]
* When the Bluetooth device name is less than 32 bytes, the remaining bytes are filled
with 00H.
[Information field to be sent when IrDA: IrCOMM, IrDA: IrOBEX, USB, RS-232C,
Bluetooth or Wireless LAN is used]
STX Sec Inq Interval Window
02H 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH 3xH
Bluetooth device name
32 bytes
To Next Page
