CHAPTER 4 TRANSMISSION SEQUENCE
B-EP Series
4-2
4.2 TPCL MODE
4.2.1 INITIAL SETTING
Writable characters, logo, and PC interface commands must be stored, before the label issue
operation.
(1) Storing writable characters and logos
NOTES: (1) The storage of writable characters or logos is only performed if it is required.
(2) When the Format Command is not sent before storing a writable character or a
logo with the same number as the already stored writable character or logo,
memory will be used with each storing.
(3) Performing other operations (storing PC interface commands and label issue
operation) after storing writable characters or logos automatically clears the
image buffer.
(4) If the storage operation is not continued after storing writable characters or logos,
the printer enters the on-line mode (label issue operation) after approx. 1.6
seconds. At the same time, the image buffer is automatically cleared.
Power ON
<New>
Format Command
Bit Map Writable
Character Command
Yes
(Add/change)
[ESC] J1: Formats flash memory.
Completion of storing
all characters
z Storing PC interface commands
z Label issue operation
No
Yes
[ESC] XD: Stores writable characters or a
logo on flash memory.
No
