CHAPTER 6 LABEL MODE (INTERFACE COMMANDS)
B-EP Series
6-4
6.3 COMMANDS RELATED TO SETTING
6.3.1 LABEL SIZE SET COMMAND [ESC] D
Function Sets the size of a label or tag.
Format [ESC] Daaaa, bbbb, cccc [LF] [NUL]
Term aaaa: Label/tag pitch
Fixed at 4 digits (in 0.1 mm units)
0100 (10.0 mm) to 9999 (999.9 mm)
bbbb: Effective print width
Fixed at 4 digits (in 0.1 mm units)
0100 (10.0 mm) to 1057 (105.7 mm)
cccc: Effective print length
Fixed at 4 digits (in 0.1 mm units)
0070 (7.0 mm) to 9970 (997.0 mm)
The size depends on the type of the new portable printer.
B-EP2DL-GHxx B-EP4DL-GHxx
Label/tag pitch 10 × 999.9 mm 10 × 999.9 mm
Effective print width 48.0 mm 104.0 mm
Effective print length 997.0 mm 997.0 mm
To Next Page
