Toshiba B-EP4DL-GH32-QM-R Interface Specification

CHAPTER 8 ESC/POS MODE (INTERFACE COMMANDS)
B-EP Series
8-39
8.10.24 PAGE MODE PRINT DIRECTION SET COMMAND [ESC] T
Function Selects a print direction and print starting point in page mode.
Format [ESC] Tn
Term ASCII: ESC T
Hex: 1Bh 54h
[Parameter]
n: Selecting print direction and starting point 0 ≤ n ≤ 3 (00h ≤ n ≤ 03h)
48 ≤ n ≤ 51 (30h ≤ n ≤ 33h)
N Print direction
0, 48
Left → Right
Top left (A in the
figure on the right)
1, 49
Bottom → Top
Bottom left (B in the
figure on the right)
2, 50
Right → Left
Bottom right (C in
the figure on the
right)
3, 51
Top → Bottom
Top right (D in the
figure on the right)
Default value n: 0
Explanation (1) If this command is received while the printer is in standard mode, the defined
parameter setting will be applied after switching to page mode.
(2) The position where characters are expanded is the starting position in the print area
defined by the Page Mode Print Area Set Command ([ESC] W).
Reference Switching to Standard Mode Command ([ESC] S)
Switching to Page Mode Command ([ESC] L)
Page Mode Print Area Set Command ([ESC] W)
Relative Position Set Command ([ESC] \)
Page Mode Relative Position in Vertical Direction Set Command ([GS] \)
(
Reference
)
(
Print area
)
Paper feed direction →
