CHAPTER 4 TRANSMISSION SEQUENCE
B-EP Series
4-6
4.2.3 HANDLING OF RECEIVED DATA BY COMMAND
4.2.3.1 BIT MAP FONT FORMAT COMMAND
If communication is interrupted while the Bit Map Font Format Command is running and no
subsequent data is transmitted in the next transmission, a command error occurs. If
communication is interrupted by the command separator, printing is available when the print data
is retransmitted from the beginning in the next transmission.
[Command transmission and print results (Examples)]
(1) When transmitting print data for two labels as usual,
{AY;+00,1,3|}
{D0130,0480,0100|}
{C|}
{LC;0010,0010,0470,0060,1,2|} 1st label data
{PC00;0030,0050,2,1,a,00,B,+0000000000|}
{RC00;2inch 0001|}
{XS;I,0001,0000C2011|}
{AY;+00,1,3|}
{D0130,0480,0100|}
{C|}
{LC;0010,0010,0470,0060,1,2|} 2nd label data
{PC00;0030,0050,2,1,a,00,B,+0000000000|}
{RC00;2inch 0002|}
{XS;I,0001,0000C2011|}
Print result: c and d as shown below are printed in a row.
c
d
2 inch 0001
2 inch 0002
