CHAPTER 8 ESC/POS MODE (INTERFACE COMMANDS)
B-EP Series
8-50
8.10.34 CHINESE CHARACTER PRINT MODE ALL SET COMMAND [FS] !
Function Specifies printing mode for Chinese characters altogether.
Format [FS] !
Term ASCII: FS!
Hex: 1Ch 21h
[Parameter]
n: Specifying character control of Chinese character 0 ≤ n ≤ 255 (00h ≤ n ≤ FFh)
b7 b0
-- -- -- -- --
Default value n: 0
Explanation (1) If both double width and double height are specified, a character size will be
quadrupled (double width × double height).
(2) Chinese characters including space on both sides of them are underlined.
However, a portion skipped by the Horizontal Tab Command ([HT]) or a character
rotated 90 degrees clockwise is not underlined.
(3) The width of an underline for Chinese characters is determined in accordance with
the width defined by the Chinese Character Underlining Set Command ([FS] -).
(4) If characters with different magnifications in the vertical direction coexist in the same
line, they will be aligned to the baseline.
(5) The size of Chinese characters can also be specified by the Chinese Character
Magnification Set Command ([FS] W) or Character Size Set Command ([GS] !).
But the most recently processed command is applied.
(6) Underlining for Chinese characters can also be set or canceled by the Chinese
Character Underlining Set Command ([FS] -), but the most recently processed
command is applied.
(7) The parameter setting applies to the Chinese language settings with Chinese
language implemented for the QM model (destined overseas), or to the Korean
language setting with Korean language implemented.
0: Canceling double width
1: Setting double width
0: Canceling double height
1: Setting double height
0: Canceling underlining
1: Setting underlining
