CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-33
5.6.2 BIT MAP FONT FORMAT COMMAND [ESC] PC
Function Sets the format indicating where and how the bit map font is to be printed on a label.
Format c [ESC] PCaaa; bbbb, cccc, d, e, ff (, ghh), ii, j (, Jkkll) (, Mm) (, noooooooooo)
(, Zpp) (, Pq) (= rrr ------ rrr) [LF] [NUL]
d [ESC] PCaaa; bbbb, cccc, d, e, ff (, ghh), ii, j (, Jkkll) (, Mm) (, noooooooooo)
(,Zpp) (,Pq) (; ss
1
, ss
2
, ss
3
, ------ , ss
20
) [LF] [NUL]
Term aaa: Character string number
000 to 199 (two digits, 00 to 99, also acceptable.)
bbbb: X-coordinate of the print origin of character string
Fixed at 4 digits (in 0.1 mm units)
cccc: Y-coordinate of the print origin of character string
4 or 5 digits (in 0.1 mm units)
d: Character horizontal magnification
1 to 9 (in magnifications)
* Two-digit designation enables the magnifications in 0.5 units.
(05 ~ 95: 0.5 to 9.5 magnifications)
The magnification can be designated in 0.1 units between 0.5 to 1.
(06 ~ 0.9: 0.6 to 0.9 magnifications)
d d
Designation in 0.5 magnifications: 0 or 5
(5 to 9 , up to 1 magnification)
Designation in magnifications: 0 to 9
e: Character vertical magnification
1 to 9 (in magnifications)
* Two-digit designation enables the magnifications in 0.5 units.
(05 ~ 95: 0.5 to 9.5 magnifications)
The magnification can be designated in 0.1 units between 0.5 to 1.
(06 ~ 09: 0.6 to 0.9 magnifications).
e e
Designation in 0.5 magnification units: 0 or 5
(5 to 9, up to 1 magnification)
Designation in magnifications: 0 to 9
ff: Type of font 203-dpi print head
A: Times Roman (Medium) 12 points
B: Times Roman (Medium) 15 points
C: Times Roman (Bold) 15 points
D: Times Roman (Bold) 18 points
E: Times Roman (Bold) 21 points
F: Times Roman (Italic) 18 points
G: Helvetica (Medium) 9 points
H: Helvetica (Medium) 15 points
I: Helvetica (Medium) 18 points
J: Helvetica (Bold) 18 points
K: Helvetica (Bold) 21 points
L: Helvetica (Italic) 18 points
To Next Page
